| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | PTO GEARBOX (6001967 E) 400/C5966 400/Z1584 | 1 | $19,491.50 | |||
| 3 | 6C DRIVESHAFT 165mm 400/C3454 | 1 | $1,991.61 | |||
| 4 | 2ISU F PULLEY - 5C SHAFT 333/V3163 400/N7696 | 1 | $209.27 | |||
| 6 | CAP SCREW M14 x 170 G8.8 400/C9640 | 1 | $17.60 | |||
| 7 | 7C DRIVESHAFT 190mm 400/C3465 | 1 | $1,884.53 | |||
| 9 | fpto guard 400/A8196 | 1 | $153.81 | |||
| 10 | CAP SCREW M10 x 50 G10.9 335/A6002 | 1 | $7.52 | |||
| 11 | DUAL OUTPUT SPEED SENSOR 716/D2727 | 1 | $435.60 | |||
| 12 | CUT-OUT SWITCH PTO 335/B6340 | 1 | $118.76 | |||
| 14 | BOLT M16x60 1315/3714D | 1 | $11.03 | |||
| 15 | M16 LOCK NUT 1370/0603D | 1 | $21.78 | |||
| 16 | WASHER M16 PLAIN 1420/0011D | 1 | $1.43 | |||
| 17 | CAP SCREW M12x50 1391/3512D | 1 | $24.43 | |||
| 18 | WASHER LOCK M10 823/10261 | 1 | $5.93 | |||
| 20 | 6C DRIVE COUPLING 400/C3495 | 1 | $528.95 | |||
| 21 | CAP SCREW M12 x 60 G10.9 400/C6053 | 1 | $5.96 | |||
| 22 | WASHER LOCK M12 332/A0976 | 1 | $11.60 | |||
| 24 | NUT M14 HEX SELF LOCK 1370/0503D | 1 | $15.54 | |||
| 25 | Cap screw 1391/3505D | 1 | $16.93 | |||
| 26 | M14 NORDLOCK WASHER 333/R3377 | 1 | $8.80 | |||
| 27 | TRANSFER BOX - 21 SPLINE (6001968 B) 400/C9369 | 1 | $4,422.58 | |||
| 28 | FH Hose plate 400/E8197 | 1 | $35.40 | |||
| 29 | THIN HEXAGON 1370/0502Z | 1 | $2.59 | |||
| 30 | CABLE TIE - BLACK 300mm 121/77603 | 1 | $0.95 | |||
Showing 1 to 24 of 24 parts
Related Assemblies
-
DIAG-F700-10-1-393731 F700-10-1 BEVEL / PTO / TRANSFER GEARBOX INSTALLATION ASSEMBLIES FRONT PTO 6 SPLINE
View Diagram -
DIAG-F710-5-5-393731 F710-5-5 PTO GEARBOX 21 SPLINE PTO ASSEMBLY
View Diagram -
DIAG-F690-10-1-393731 F690-10-1 OTHER PS/AS/CVT PARTS HARNESS TRAY SUPPORT ASSEMBLY
View Diagram
