Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | TORQUE CONVERTER 04/500100 | 1 | $1,882.73 | |||
| 2 | DRIVE PLATE KIT 04/500300 | 1 | $356.27 | |||
| 7 | BOLT M12X50 1315/3512 | 1 | $1.76 | |||
| 8 | NUT 1370/0403 | 1 | $6.91 | |||
| 9 | M12 X 60 BOLT 1315/3514Z | 1 | $10.29 | |||
| 10 | BOLT M12x70 1315/3516Z | 1 | $3.44 | |||
| 11 | SET M12 X 45 HT 1315/0511Z | 1 | $1.75 | |||
| 12 | DOWEL 02/101370 | 1 | $19.27 | |||
| 13 | BOLT M12x100 1315/3520Z | 1 | $10.52 | |||
| 14 | SET M12 L-40mm HT 1315/0510Z | 1 | $2.57 | |||
| 15 | FILL.TUBE.TRANS.P/SHIFT. 158/30456 | 1 | $96.22 | |||
| 16 | DIP STICK ASSEMBLY 159/69928 | 1 | $10.95 | |||
| 17 | 1"SEALASTIC NUT 155/10600 | 1 | $68.77 | |||
| 18 | RETAINING BRKT. 157/12201 | 1 | $170.53 | |||
| 20 | HOSE CLAMP 821/00280 | 1 | $10.35 | |||
Showing 1 to 15 of 15 parts
Related Assemblies
-
DIAG-F7-13-1-400160 F7-13-1 PIPEWORK PERMANENT 4WD POWERSHIFT TRANSMISSIONS
View Diagram -
DIAG-F7-15-1-400160 F7-15-1 TRANSMISSION MOUNTING POWERSHIFT
View Diagram -
DIAG-F7-12-1-400160 F7-12-1 PIPEWORK 2/4 WHEEL DRIVE POWERSHIFT TRANSMISSION
View Diagram
