Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | WA LAYSHAFT CLUTCH HSG 459/50655 459/M4577 | 1 | $2,282.92 | |||
| 4 | GEAR-46T & PLATE CARRIER 459/M3300 | 1 | $241.41 | |||
| 5 | BEARING - TAPER ROLLER 907/20032 | 1 | $60.40 | |||
| 6 | BEARING - TAPER ROLLER 907/20034 | 1 | $91.41 | |||
| 7 | THRUST BEARING INA REF AX 917/50300 | 1 | $35.21 | |||
| 8 | NEEDLE ROLLER BEARING 917/10000 | 1 | $58.84 | |||
| 9 | WASHER - THRUST - CONICAL 823/M4464 | 1 | $10.85 | |||
| 10 | WASHER-THRUST KIT 823/10420 | 1 | $385.32 | |||
| 11 | CIRCLIP-EXTERNAL 826/10468 | 1 | $3.63 | |||
| 12 | CIRCLIP 150mm - INTERNAL 821/M8880 | 1 | $8.88 | |||
| 13 | WASHER-SPRING RETAINER 823/10266 | 1 | $32.23 | |||
| 14 | OIL BAFFLE PLT Gearbox 331/16558 | 1 | $3.82 | |||
| 15 | COMPRESSION SPRING 814/00345 | 1 | $22.20 | |||
| 16 | G.A. PISTON - CLUTCH 459/M2179 | 1 | $101.80 | |||
| 17 | O'RING 828/10181 | 1 | $4.06 | |||
| 19 | O'RING 828/10180 | 1 | $4.03 | |||
| 20 | FRICTION PLATE 331/16520 | 1 | $32.83 | |||
| 21 | Plate counter, clutch 331/16516 | 1 | $21.40 | |||
| 22 | PRESSURE PLATE 331/16517 | 1 | $39.96 | |||
| 23 | SHIM PLATE CLUTCH 331/16519 | 1 | $8.60 | |||
| 24 | SEAL RING PTFE DIA.35 904/50020 | 1 | $5.17 | |||
| 25 | PRESSURE PLATE 331/16550 | 1 | $48.84 | |||
| 26 | CIRCLIP EXTERNAL 821/00296 | 1 | $11.93 | |||
| A | G.A. LAYSHAFT CLUTCH 459/10195 | 1 | $3,408.69 | |||
Showing 1 to 24 of 24 parts
