Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 10 | SHAFT - 4WD OUTPUT 459/M6870 | 1 | $227.06 | |||
| 20 | SEALING RING 4WD PTFE 904/14300 | 1 | $2.63 | |||
| 30 | PISTON HOUSING - 4WD 459/P9870 | 1 | $95.13 | |||
| 40 | PISTON-4WD CLUTCH 445/15701 445/M6092 | 1 | $201.18 | |||
| 50 | THRUST WASHER-4WD CLUTCH 459/M6908 | 1 | $45.67 | |||
| 60 | FRICTION PLATE - 4WD 459/M8185 | 1 | $14.55 | |||
| 70 | COUNTER PLATE 459/M8186 | 1 | $6.42 | |||
| 80 | HMH PRESSURE PLATE 459/M8465 | 1 | $266.29 | |||
| 90 | ACTUATING SLEEVE 4WD CLUT 459/M8184 | 1 | $94.94 | |||
| 100 | DISC SPRING 445/05110 | 1 | $126.40 | |||
| 110 | CLUTCH DRUM M/C 459/M9414 | 1 | $240.76 | |||
| 120 | DISC SPRING 445/05118 | 1 | $380.13 | |||
| 130 | STEEL RING 445/05114 | 1 | $20.50 | |||
| 140 | CIRCLIP INTERNAL J128 821/M8194 | 1 | $326.64 | |||
| 150 | O RINGS DOWTY REF 200 230 2403/0221 | 1 | $6.69 | |||
| 160 | O'RING 200 253 4470 2403/0244 | 1 | $6.06 | |||
| 170 | SHIM PLATE 332/M4101 | 1 | $11.93 | |||
| 170 | SHIM PLATE - 0.8mm 459/M8205 | 1 | $6.50 | |||
| 180 | BEARING TAPER ROLLER 907/52800 | 1 | $103.83 | |||
| 190 | THRUST WASHER 445/05003 823/10582 | 1 | $98.49 | |||
| 200 | ROLLER BEARING HK 4020A 917/02600 | 1 | $36.48 | |||
| 210 | RETAINER-DISC SPRING-4WD 459/M8470 | 1 | $101.09 | |||
| A | G.A. CLUTCH - 4WD 4CX 459/M4234 | 1 | $1,316.28 | |||
Showing 1 to 23 of 23 parts
Related Assemblies
-
DIAG-F615-15-7-394845 F615-15-7 442/M5715 AUTOSHIFT (6 SPEED) 4WD, LUC
View Diagram -
DIAG-F655-5-1-394845 F655-5-1 VALVE CONTROL 4 SPEED LUC VALVE ASSEMBLY
View Diagram -
DIAG-F610-19-15-394845 F610-19-15 442/M5712 POWERSHIFT (4 SPEED) 4WD, LUC
View Diagram
