Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| ADAPTOR 445/42605 | 1 | $42.46 | ||||
| ADAPTOR-TEE MAINLINE P 816/13386 | 1 | $18.97 | ||||
| BOLT 1316/0311 | 1 | $0.50 | ||||
| O RING 828/00190 | 1 | $1.88 | ||||
| RUBBER GROMMET.GEARBOX. 445/13703 | 1 | $91.89 | ||||
| SETSCREW M8 x 12 1321/0301Z | 1 | $4.90 | ||||
| 3 | PLUG-RELIEF VALVE 816/80041 | 1 | $37.00 | |||
| 3 | REAR CASING M/CPS760 4SPD 459/30301 | 1 | $4,493.85 | |||
| 3 | WASHER 1406/0018 | 1 | $4.09 | |||
| 4 | BOLT.FLANGED M10x50(KANBAN) 826/10613 | 1 | $5.75 | |||
| 5 | DOWEL 445/14001 | 1 | $6.66 | |||
| 6 | SCREW M10X35 1316/0409Z | 1 | $2.18 | |||
| 7 | BREATHER 460/17604 | 1 | $18.90 | |||
| 8 | SENSOR SPEED 12V DT04 728/D4742 | 1 | $527.55 | |||
| 10 | SPRING-SOLENOID ADAPTOR 814/00412 | 1 | $10.95 | |||
| 11 | BALL 16 dia. 916/10014 | 1 | $2.62 | |||
| 12 | TAPER PLUG - 3/8 BSP(KANBAN) 816/80053 | 1 | $12.08 | |||
| 13 | GASKET 813/50027 | 1 | $2.11 | |||
| 15 | SETSCREW M8 x 16 1321/0303Z | 1 | $1.49 | |||
| 16 | FILTER ADAPTOR 816/15184 | 1 | $67.41 | |||
| 17 | FILTER (NOW SUPERSEDED BY 581/M8563) 581/18063 581/M7012 | 1 | $17.79 | |||
| 18 | O RING (200-016-4470) 828/00236 | 1 | $0.23 | |||
| 19 | TAPER PLUG - 1/4" BSP 816/80052 | 1 | $11.57 | |||
| 20 | WASHER BONDED 1/4 BSP 1406/0011 | 1 | $1.52 | |||
| 21 | TAPER PLUG - 1/8"BSP 816/80051 | 1 | $4.83 | |||
| 22 | DRAIN PLUG - NON-MAGNETIC 816/80037 | 1 | $25.01 | |||
| 23 | WASHER BONDED 1" BSP 1406/0021 | 1 | $6.00 | |||
| 24 | PRESSURE TEST POINT 1/4" 45/905000 45/MM7149 | 1 | $36.65 | |||
| 25 | SWITCH - OIL PRESSURE 701/80319 701/80626 | 1 | $55.74 | |||
| 28 | SUCTION STRAINER 32/925344 | 1 | $311.23 | |||
| 29 | O'RING (200-120-4470) 2403/0111 | 1 | $1.86 | |||
| 30 | COVER-BRAKE CAVITY 331/44557 | 1 | $910.62 | |||
| 31 | SETSCREW-FLANGED M10X20 826/01416 | 1 | $31.80 | |||
| 36 | O RING 200/257/4470/99 828/00331 | 1 | $7.17 | |||
| 37 | 'O' RING 828/10266 | 1 | $3.92 | |||
Showing 1 to 35 of 35 parts
Related Assemblies
-
DIAG-F6-3-1-395097 F6-3-1 TRANSMISSION ASSY PS760 4 SPEED 442/00140,00220,00320 GERMAN 40KPH
View Diagram -
DIAG-F6-3-11-395097 F6-3-11 TRANSMISSION EXTERNAL COMPONENTS 2WS 4WD 4 SPEED 40KPH 442/00220 GERMAN
View Diagram -
DIAG-F6-2-95-395097-11178276 F6-2-95 PUMP, TRANSMISSION & MAIN HYD PUMP DRIVE 442/00130,00210,00310 4 SPEED
View Diagram
