Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 4 | SET-SCREW M10 L-_30mm 1315/0408Z | 1 | $1.22 | |||
| 6 | SET SCREW-M10 X 35 1321/0409Z | 1 | $1.97 | |||
| 7 | ADAPTOR 1/2BSP X 5/8BSP 1606/0017 | 1 | $14.01 | |||
| 8 | WASHER 1406/0018 | 1 | $4.09 | |||
| 9 | PLUG-RELIEF VALVE 816/80041 | 1 | $37.00 | |||
| 10 | SPRING (T.C. RELIEF) 814/00222 | 1 | $8.72 | |||
| 11 | 14.DIA BALL RB14910TG20T 916/00008 | 1 | $1.22 | |||
| 12 | TAPER PLUG - 3/8 BSP(KANBAN) 816/80053 | 1 | $12.08 | |||
| 13 | GASKET 813/50027 | 1 | $2.11 | |||
| 14 | SUCTION STRAINER 32/902200 | 1 | $125.88 | |||
| 15 | SETSCREW M8 x 16 1321/0303Z | 1 | $1.49 | |||
| 16 | ADAPTOR 1/2"BSP(M)x3/4"UN 816/17099 | 1 | $161.39 | |||
| 18 | O RING (200-016-4470) 828/00236 | 1 | $0.23 | |||
| 20 | WASHER BONDED 3/8" BSP(KANBAN) 1406/0015 | 1 | $1.52 | |||
| 21 | BOLT M10 X 100 1321/3420Z | 1 | $7.49 | |||
| 24 | TAPER PLUG - 1/8"BSP 816/80051 | 1 | $4.83 | |||
| 30 | PLUG - DRAIN 816/80047 | 1 | $76.43 | |||
| 31 | WASHER BONDED 1"BSP 1406/0026 | 1 | $11.54 | |||
| 32 | PRESSURE TEST POINT 3/8" 45/908300 45/MM7150 | 1 | $31.17 | |||
| 33 | 3/8" BSP PLUG 816/80005 | 1 | $3.58 | |||
| 33 | SWITCH - OIL PRESSURE 701/43700 | 1 | $115.67 | |||
Showing 1 to 21 of 21 parts
Related Assemblies
-
DIAG-F6-10-1-401766 F6-10-1 SWITCH, SOLENOID POWERSHIFT TRANSMISSION
View Diagram -
DIAG-F6-12-1-401766 F6-12-1 PIPEWORK 2/4 WHEEL DRIVE POWERSHIFT TRANSMISSION
View Diagram -
DIAG-F6-13-1-401766 F6-13-1 PIPEWORK PERMANENT 4WD POWERSHIFT TRANSMISSIONS
View Diagram
