Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| M12 X 60 BOLT 1315/3514Z | 1 | $10.29 | ||||
| SEALING WASHER 823/00264 | 1 | $1.92 | ||||
| TUBE FILLER W.A. 830/10525 | 1 | $258.28 | ||||
| Tube Trans.Oil Dip 830/11211 | 1 | $719.00 | ||||
| 1 | TORQUE CONVERTER 04/500100 | 1 | $1,882.73 | |||
| 2 | DRIVE PLATE KIT 04/500300 | 1 | $356.27 | |||
| 7 | M12 X 50 BOLT 1315/3512Z | 1 | $3.38 | |||
| 8 | NUT M12 STD SELF LOCK 1370/0403Z | 1 | $2.11 | |||
| 8 | NUT M16 STD SELF LOCK 1370/0603Z | 1 | $2.66 | |||
| 10 | BOLT M12x70 1315/3516Z | 1 | $3.44 | |||
| 11 | SET M12 X 45 HT 1315/0511Z | 1 | $1.75 | |||
| 12 | DOWEL 02/101370 | 1 | $19.27 | |||
| 13 | BOLT M12x100 1315/3520Z | 1 | $10.52 | |||
| 13 | BOLT M12X130 1315/3523Z | 1 | $16.86 | |||
| 14 | SET M12 L-40mm HT 1315/0510Z | 1 | $2.57 | |||
| 16 | DIPSTICK 160/01313 | 1 | $49.69 | |||
| 16 | DIPSTICK GEARBOX 162/00771 | 1 | $66.82 | |||
| 17 | 1"SEALASTIC NUT 155/10600 | 1 | $68.77 | |||
| 18 | BRACKET 331/40261 | 1 | $45.46 | |||
| 18 | BRACKET GEARBOX FI 162/01582 | 1 | $8.08 | |||
| 20 | HOSE CLAMP 821/00280 | 1 | $10.35 | |||
| 21 | SET SCREW M10x20 1315/0405Z | 1 | $4.23 | |||
| 22 | WASHER M10 PLAIN 1425/0008Z 1420/0008D | 1 | $0.23 | |||
Showing 1 to 23 of 23 parts
Related Assemblies
-
DIAG-F5-7-1-400570 F5-7-1 COOLER, OIL & INSTALLATION
View Diagram -
DIAG-F5-1-1-400570 F5-1-1 TRANSMISSION JCB SYNCRO SHUTTLE
View Diagram -
DIAG-G1-4-1-400570 G1-4-1 BRAKE SYSTEM CHASSIS 4WS 520
View Diagram
