Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | DIPSTICK TRANS 331/21212 | 1 | $214.51 | |||
| 2 | Tube dipstick tran 331/23315 | 1 | $248.67 | |||
| 3 | Bracket 331/23327 | 1 | $158.94 | |||
| 4 | GROMMET (P493) 2410/0306 | 1 | $19.90 | |||
| 5 | SET-SCREW M_8 L-_20mm 1315/0305D | 1 | $10.29 | |||
| 7 | WA FILLER TRANS OIL 332/T1971 | 1 | $867.51 | |||
| 8 | FILLER CAP (VENTED) 477/01134 | 1 | $63.15 | |||
| 10 | (W) (P) CLIP - WORMDRIVE 25/40mm 2201/0007 | 1 | $4.66 | |||
| 11 | GEARBOX FILLER 477/00419 | 1 | $106.80 | |||
| 12 | WASHER BONDED 1"BSP 1406/0026 | 1 | $11.54 | |||
| 13 | SET-SCREW M_8 L-_30mm 1315/0308D | 1 | $1.63 | |||
| 14 | SETSCREW M8x35 1315/0309D | 1 | $2.40 | |||
| 15 | WASHER M_8 PLAIN 1420/0007Z 1420/0007D | 1 | $0.20 | |||
| 16 | NUT M8 STD SELF LOCK 1370/0203D | 1 | $1.75 | |||
| 17 | TRANSMISSION OIL FILLER LABEL 817/00150 | 1 | $46.54 | |||
Showing 1 to 15 of 15 parts
Related Assemblies
-
DIAG-F5-4-1-393558 F5-4-1 DIPSTICK & FILLER TRANSMISSION MECHANICAL SPOOL VALVE BUILD
View Diagram -
DIAG-F5-4-5-393558 F5-4-5 DIPSTICK & FILLER TRANSMISSION with Spring
View Diagram -
DIAG-F6-1-2-393558 F6-1-2 GEARBOX, RANGE AIRSHIFT
View Diagram
