Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 3 | GA DRIVEHEAD NORM M30 LH 458/M1887 | 1 | $4,985.18 | |||
| 7 | HOSE ADAPTOR 458/20611 | 1 | $51.49 | |||
| 8 | BLEED SCREW(KANBAN) 816/60040 | 1 | $0.00 | |||
| 9 | BOLT M12 x 65 LG 1321/3515Z | 1 | $4.72 | |||
| 10 | MULTIGASKET 4102/1200 4102/1212 | 1 | $30.21 | |||
| 13 | SERIAL PLATE-JCB 817/02980 | 1 | $21.43 | |||
| 14 | CHOBERT RIVET 826/01231 | 1 | $4.26 | |||
| 15 | TRANSIT PLUG REF:10549 835/00181 | 1 | $21.74 | |||
| 16 | PIVOT PIN W.A. 911/25700 911/22800 | 1 | $24.06 | |||
| 17 | BOLT 1321/0405Z | 1 | $2.15 | |||
| 18 | PTR NEW SEALS 458/M3585 | 1 | $688.78 | |||
| 22 | PLUG-TRANSIT 458/20340 | 1 | $4.11 | |||
| 23 | LOCTITE 495 BO20G EN/DE 4103/0900 | 1 | $41.23 | |||
| 24 | G.A. STEER LINK 448/28700 | 1 | $547.72 | |||
| 25 | BOLT M12 X 55L VERBUS RIP 826/01435 | 1 | $24.54 | |||
| 26 | SENSOR DISC PTR 448/16403 | 1 | $39.07 | |||
| 27 | CAP NIPPLE 835/00017 835/00017A | 1 | $4.12 | |||
| 38 | DOMED BOLT 826/01327 | 1 | $8.50 | |||
| 40 | BREATHER PLUG 450/13302 | 1 | $11.15 | |||
| 41 | 3/4" BSP TAPER PLUG 816/M3849 | 1 | $6.69 | |||
| 43 | 3/4" BSP TAPER PLUG - MAG 450/10216 816/M3848 | 1 | $11.39 | |||
| 45 | WA-STEER SENSOR AXLE BRKT 458/M7828 | 1 | $130.19 | |||
| A | GA SD55 PAD MT AXLE 448/M7814 | 1 | $15,486.04 | |||
Showing 1 to 23 of 23 parts
Related Assemblies
-
DIAG-F100-10-5-400749 F100-10-5 FRONT AXLE INSTALLATION ASSEMBLIES MOUNTING
View Diagram -
DIAG-E330-15-1-400749 E330-15-1 VALVES STEERING COMPONENTS MANUAL
View Diagram -
DIAG-E130-80-1-400749 E130-80-1 HYDRAULIC CIRCUITS CHASSIS STEERING MANUAL STEER, HC
View Diagram
