Kubota GR2000G E55000 ENGINE SUPPORT Parts Diagram
Exploded-view parts diagram "E55000 ENGINE SUPPORT" for the Kubota GR2000G. 16 parts are listed in this assembly. Click a numbered reference on the drawing, or use the search box, to see the genuine Kubota part number with price and stock, then add it to your cart. Supplied by Scholten's Equipment, authorized Kubota dealer with stores in Lynden and Burlington, Washington.
Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| GROMMET 69341-41470 | 1 | $7.46 | ||||
| SHEET, DUST PROO K1253-84550 | 1 | $20.74 | ||||
| TRIM RD411-41510 | 1 | $3.29 | ||||
| 010 | BOLT, FLANGE 01130-51040 01133-51040 | 1 | $2.87 | |||
| 020 | Flange Nut 02771-60100 02771-70100 | 1 | $2.93 | |||
| 030 | PIPE, DRAIN K1261-81110 | 1 | $57.57 | |||
| 040 | BRACKET, ENGINE K1261-81122 Discontinued | 1 | $88.64 | |||
| 050 | Bolt - Equipment Fastener 01130-51025 01133-51025 | 1 | $2.36 | |||
| 070 | COVER, SHAFT K1261-81210 | 1 | $23.63 | |||
| 080 | COVER, ENGINE K1261-81513 | 1 | $83.19 | |||
| 090 | TRIM, ENGINE K3211-81550 | 1 | $20.78 | |||
| 100 | GROMMET 54721-38340 | 1 | $10.35 | |||
| 110 | Flange Bolt - M8 x 1.25 x 20 mm 01754-50820 | 1 | $4.70 | |||
| 120 | SPONGE 1, DUSTPR K1261-81610 | 1 | $4.99 | |||
| 130 | SPONGE 4, DUSTPR K1261-81640 | 1 | $13.49 | |||
| 140 | SPONGE 6, DUSTPR K1261-81660 | 1 | $18.11 | |||
Showing 1 to 16 of 16 parts
