Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 2 | VALVE, HBCV - DIPPER 25/222582 | 1 | $751.30 | |||
| 3 | WA DIPPER RAM PIPE HBCV 332/W6615 | 1 | $223.89 | |||
| 4 | WA DIPPER RAM PIPE HBCV 332/V6945 | 1 | $354.08 | |||
| 5 | BOLT M10x65 1315/3415D | 1 | $7.10 | |||
| 6 | WASHER M10 PLAIN 1425/0008Z 1420/0008D | 1 | $0.23 | |||
| 7 | SET-SCREW M_8 L-_25mm 1315/0307D | 1 | $0.37 | |||
| 8 | NUT M8 STD SELF LOCK 1370/0203D | 1 | $1.75 | |||
| 9 | WASHER M_8 PLAIN 1420/0007Z 1420/0007D | 1 | $0.20 | |||
| 10 | ADAPTOR ORFS M -08/SAE ORB -12 1751/1208 | 1 | $30.13 | |||
| 11 | ADAPTOR ORFS M -04/SAE ORB -06 1751/0604 | 1 | $3.79 | |||
| 12 | DAPTOR ORFS M-04/SAE ORB-06 ELB 1754/0604 | 1 | $6.94 | |||
| 13 | GUARD - DIPPER HBCV 331/46375 | 1 | $63.52 | |||
| 14 | WA PLATE - DIPPER HBCV 335/08287 | 1 | $24.09 | |||
| 15 | SET-SCREW M10 L-_25mm 1315/0407D | 1 | $0.62 | |||
Showing 1 to 14 of 14 parts
Related Assemblies
-
DIAG-E465-13-1-398209 E465-13-1 RAMS DIPPER ASSEMBLY SHORT STROKE, HBCV
View Diagram -
DIAG-E460-5-2-398209 E460-5-2 RAMS BOOM RAM
View Diagram -
DIAG-J100-1-1-398209 J100-1-1 TRACK STEEL ASSEMBLY, 450mm
View Diagram
