| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| WASHER 1/8"BSP ALUMINIUM 1403/0001 | 1 | $0.65 | ||||
| 1 | ASSY ENDCAP 70*50 (594/00192) 594/14264 | 1 | $308.91 | |||
| 2 | Seal Wiper 50MM 2411/8606 2411/8606P | 1 | $3.63 | |||
| 3 | O RING 64.0 X 3 - BAGS OF 10 2302/0108 | 1 | $16.31 | |||
| 4 | ROD SEAL.50X60X8.0 P38 2411/0526 | 1 | $10.23 | |||
| 4A | ROD BEARING FRJ 50-55-30 2411/9006 | 1 | $14.46 | |||
| 6 | P/HEAD ASSY 70x50 (595/10054) 595/27717 | 1 | $311.68 | |||
| 7 | O RING. 50.0 x 3 2302/0155 | 1 | $30.50 | |||
| 8 | DOWEL 6*20Mmm (KANBAN) 826/01182 | 1 | $8.07 | |||
| 9 | WEAR RING 70 x 6.8 2411/7912 | 1 | $11.42 | |||
| 10 | PISTON SEAL 70 x 6 2411/1131 | 1 | $36.88 | |||
| 12 | WA PIPE G1/2*2392**NSP** 551/90407 | 1 | $322.84 | |||
| 15 | CHECK VALVE BODY 928/50031 | 1 | $64.69 | |||
| 16 | RAM SUPP.BRKT. 556/90026 | 1 | $34.30 | |||
| 17 | RAM SUPPORT PRESSING 556/90038 | 1 | $13.26 | |||
| 18 | SPRING STEEL BUSH 1211/0021 | 1 | $93.25 | |||
| 19 | GREASE NIPPLE G1/8A 333/Y6602 1450/0001 | 1 | $0.70 | |||
| 20 | GREASE EXTN.TUBE 653/00364 | 1 | $81.44 | |||
| 21 | ADAPTOR 1/8BSP -1/4BSP 816/20039 | 1 | $28.69 | |||
| 22 | ELBOW ADAPTOR 816/00420 | 1 | $6.23 | |||
| 25 | C-V CBDL-LJN-2.3:1-310bar 25/997500 | 1 | $519.65 | |||
| 25A | SEAL KIT 25/949303 | 1 | $181.91 | |||
| 30 | Kit Seal 991/00105 991/00105P | 1 | $170.68 | |||
Showing 1 to 23 of 23 parts
