Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | PIVOT PIN SEAL DIA 65 813/00414 | 1 | $57.03 | |||
| 3 | PIPE HD SIDE 1"X346.2 663/00923 | 1 | $218.27 | |||
| 5 | END CAP ASSEMBLY (594/00056) OTP 594/14036 | 1 | $1,211.73 | |||
| 8 | DOWEL 12x35LG(KANBAN) 826/01159 | 1 | $21.83 | |||
| 9 | WEAR RING 130-125 x 14.8 2411/7922 | 1 | $10.61 | |||
| 10 | PISTON SEAL 130-109 x 7.8 2411/1143 | 1 | $29.11 | |||
| 11 | O RING 70.0 X 5.0 595/27713 2302/0308 | 1 | $47.23 | |||
| 12 | M/C SPACER 70-110-105 (426Z Shovel) 829/30432 | 1 | $188.20 | |||
| 13 | LINER BRG 426Z/436 446Z 809/00140 | 1 | $102.14 | |||
| 14 | PIVOT PIN SEAL 75-85-6 813/00415 | 1 | $86.35 | |||
| 15 | GREASE NIPPLE G1/8A 333/Y6602 1450/0001 | 1 | $0.70 | |||
| 16 | SCREW 991/00120 991/00120P | 1 | $183.99 | |||
Showing 1 to 12 of 12 parts
Related Assemblies
-
DIAG-E100-1-1-404694 E100-1-1 HYDRAULIC CIRCUIT INSTALLATION ASSEMBLIES STEER HYDRAULICS ASSEMBLY
View Diagram -
DIAG-E3-49-1-404694 E3-49-1 VALVE COMPONENTS TIE RODS AND INTERSECTION SEAL KIT
View Diagram -
DIAG-E120-1-1-404694 E120-1-1 HYDRAULIC CIRCUITS LOADER END CIRCUIT AUXILIARY LOADER END HYDRAULICS
View Diagram
