Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | BOLT M20x60mm 826/01666 | 1 | $37.40 | |||
| 2 | (W) (P) WASHER M20 PLAIN 1420/0012Z | 1 | $2.82 | |||
| 4 | ABI STEER RAM (557/60092) ARMY GREEN) 128/17254 | 1 | $2,492.69 | |||
| 5 | SEAL KIT SERVICE 991/00157 | 1 | $151.10 | |||
| 6 | ROD SEAL.50X60X8.0 P38 2411/0526 | 1 | $10.23 | |||
| 7 | ROD WIPER 50-60-7 2411/8706 2411/8715 | 1 | $19.40 | |||
| 8 | O RING.80X5.METRIC RAMS 2302/0310 | 1 | $30.53 | |||
| 9 | PISTON SEAL 90-74 x 6 2411/1135 | 1 | $128.06 | |||
| 10 | WEAR RING 90 x 9.4 2411/7918 | 1 | $20.24 | |||
| 11 | End Cap Kit 594/14076 | 1 | $1,073.55 | |||
| 13 | WA.CYL. + SKVD (Aws ptr) 557/70014 | 1 | $596.41 | |||
| 14 | STUB PIPE 2WD STEER RAM 655/00388 | 1 | $58.65 | |||
Showing 1 to 12 of 12 parts
Related Assemblies
-
DIAG-E4-4-2-394945 E4-4-2 RAM, CLAMSHOVEL 6 IN 1 590MM PIVOT CENTRES
View Diagram -
DIAG-E4-2-2-394945 E4-2-2 RAM SHOVEL 40MM ROD X 70MM CYLINDER
View Diagram -
DIAG-E4-1-31-394945 E4-1-31 RAM, LIFT STANDARD 50MM ROD X 90MM CYL
View Diagram
