Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | SHELF PLATE 400/S6386 | 1 | $149.81 | |||
| 2 | SHELF BRACKET LH 400/S6422 | 1 | $29.39 | |||
| 3 | SHELF BRACKET RH 400/U5820 | 1 | $32.03 | |||
| 4 | DIVERTER VALVE 70 L/min 3 401/E6616 | 1 | $346.68 | |||
| 4A | COIL 25/223556 717/20137 | 1 | $50.77 | |||
| 4B | Kit cartridge with 333/D6252 | 1 | $89.22 | |||
| 5 | VENT DRAIN VALVE 400/S9188 | 1 | $565.19 | |||
| 6 | WASHER M10 1422/0008D JHP0046 | 1 | $11.36 | |||
| 7 | SET-SCREW M10 L-_30mm 1315/0408D | 1 | $1.55 | |||
| 8 | RIVET NUT M10 826/01249 | 1 | $8.20 | |||
| 9 | WASHER M_6 PLAIN 1420/0006Z 1420/0006D | 1 | $0.42 | |||
| 10 | WASHER M_8 PLAIN 1420/0007Z 1420/0007D | 1 | $0.20 | |||
| 11 | BOLT M8x60 1315/3314Z | 1 | $2.86 | |||
| 12 | SET SCREW M6X60 1315/0214Z | 1 | $1.46 | |||
| 13 | NUT M_6 STD PLAIN 1370/0101Z 1370/0101D | 1 | $2.14 | |||
| 14 | NUT M_8 STD PLAIN 1370/0201Z 1370/0201D | 1 | $1.07 | |||
Showing 1 to 16 of 16 parts
Related Assemblies
-
DIAG-E390-45-1-394719 E390-45-1 OTHER VALVES HAND HELD TOOLS
View Diagram -
DIAG-E390-70-1-394719 E390-70-1 OTHER VALVES VALVE PILOT STABILISER
View Diagram -
DIAG-E390-35-1-394719 E390-35-1 OTHER VALVES 2 WAY 100L/MIN, 3CX COMPACT
View Diagram
