Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | 7 SPOOL VALVE - SB33-EHS1 - 100L 334/R8508 | 1 | $27,197.45 | |||
| 2 | PRESSURE TRANSDUCER 250BA 334/V7138 401/A2327 | 1 | $172.17 | |||
| 3 | PRESSURE TEST POINT M10x1 45/MM7148 | 1 | $28.13 | |||
| 4 | ADAPTOR M33x2 - G1-1/4A 816/90703 | 1 | $51.22 | |||
| 5 | ADAPTER, M27 X 2 - 1 816/13259 | 1 | $21.37 | |||
| 6 | ADAPTOR M12 x G3/8A 816/90901 | 1 | $35.01 | |||
| 7 | ADAPTOR: M27x2 816/90714 | 1 | $32.69 | |||
| 8 | WASHER 3/8IN LARGE 1412/0003D | 1 | $0.57 | |||
| 9 | RESILIENT MOUNT 141/00936 | 1 | $17.97 | |||
| 10 | STUD M10 X 55 LONG 826/11526 | 1 | $21.10 | |||
| 11 | NUT M10 STD SELF LOCK 1370/0303Z 1370/0303D | 1 | $0.65 | |||
| 12 | SUPP BRKT - VALVE MTG - W 334/U7557 | 1 | $263.94 | |||
| 13 | WASHER M_8 PLAIN 1420/0007Z 1420/0007D | 1 | $0.20 | |||
| 14 | NUT M8 STD SELF LOCK 1370/0203D | 1 | $1.75 | |||
| 15 | SET-SCREW M_8 L-_30mm 1315/0308D | 1 | $1.63 | |||
| 16 | SET-SCREW M10 L-_30mm 1315/0408D | 1 | $1.55 | |||
| 17 | WASHER M10 PLAIN 1425/0008Z 1420/0008D | 1 | $0.23 | |||
Showing 1 to 17 of 17 parts
