E390-20-1 OTHER VALVES COMBINATION BYPASS VALVE BLOCK Parts Diagram | JCB

Scroll to zoom Click a part # to view details

Ref #	Part Number	Qty.	Avl.	Price (USD)	Action
1	ADAPTOR G1/2A-3/4UNF(M) 1620/2054	1	1 IN STOCK	$37.26	Quantity
2	Adapter tee 1/2 x 816/90541	1	AVAILABLE TO ORDER	$75.41	Quantity
3	COMBI BYPASS 402/C7175	1	AVAILABLE TO ORDER	$902.79	Quantity
4	ADAPTOR 3/4 SAE x G3/8A 816/90288	1	AVAILABLE TO ORDER	$7.55	Quantity
5	PRESSURE TEST POINT -4 SA 332/X3727	1	AVAILABLE TO ORDER	$42.28	Quantity

Showing 1 to 5 of 5 parts
