Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | 3-SPOOL VALVE ASSY 100L 333/R2259 | 1 | $26,901.83 | |||
| 2 | HYDAC PRESSURE TRANSMITTER 333/T4547 | 1 | $339.60 | |||
| 3 | ADAPTOR 478/00405 | 1 | $8.88 | |||
| 4 | STUD M10 X 55 LONG 826/11526 | 1 | $21.10 | |||
| 5 | NUT M10 STD SELF LOCK 1370/0303Z 1370/0303D | 1 | $0.65 | |||
| 6 | WASHER 3/8IN LARGE 1412/0003D | 1 | $0.57 | |||
| 7 | RESILIENT MOUNT 141/00936 | 1 | $17.97 | |||
| 11 | ADAPTER, M27 X 2 - 1 816/13259 | 1 | $21.37 | |||
| 12 | ADAPTOR M12 x G3/8A 816/90901 | 1 | $35.01 | |||
| 14 | ADAPTOR M33x2 - G1-1/4A 816/90703 | 1 | $51.22 | |||
| 15 | ADAPTOR: M27x2 816/90714 | 1 | $32.69 | |||
| 20 | Plug tapered 816/82008 | 1 | $72.04 | |||
| 23 | PRESSURE TEST ADAPTOR 45/904200 | 1 | $25.74 | |||
| 24 | HARNESS EXTENSION LEAD 333/L0666 | 1 | $98.94 | |||
Showing 1 to 14 of 14 parts
Related Assemblies
-
DIAG-E190-30-1-393643 E190-30-1 HYDRAULIC INSTALLATION ASSEMBLIES QUICK RELEASE 3 SPOOL
View Diagram -
DIAG-E190-28-1-393643 E190-28-1 HOSES 3 SPOOL VALVE ASSEMBLY
View Diagram -
DIAG-E190-25-1-393643 E190-25-1 HOSES BRAIDED
View Diagram
