| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| KIT SEAL 25/606819 | 1 | $50.13 | ||||
| KIT SEAL, WITH SPR 25/617215 | 1 | $37.17 | ||||
| Relief valve 334/G9668 | 1 | $188.81 | ||||
| VALVE BLOCK - 10 SPOOL 334/U2220 | 1 | $6,027.48 | ||||
| 9 | O RING 25/607219 | 1 | $5.00 | |||
| 12 | BODY 25/607220 | 1 | $67.78 | |||
| 13 | BALL 5MM DIA 25/974621 | 1 | $6.87 | |||
| 15 | PLUG 25/607217 | 1 | $41.16 | |||
| 16 | O Ring 25/617403 | 1 | $16.16 | |||
| 17 | SCREW 25/606827 | 1 | $3.97 | |||
| 18 | ADAPTOR 25/610702 | 1 | $39.19 | |||
| 19 | O RING 25/607224 | 1 | $13.16 | |||
| 20 | O RING 25/607225 | 1 | $13.16 | |||
| 21 | NUT 25/607227 | 1 | $3.46 | |||
| 22 | LEVER 25/607226 | 1 | $27.41 | |||
| 23 | CAPSCREW 25/608607 | 1 | $38.39 | |||
| 25 | CAP SERVO 25/620814 | 1 | $229.28 | |||
| 26 | SEAT SPRING 25/608609 | 1 | $14.10 | |||
| 27 | O RING 25/608606 | 1 | $7.99 | |||
| 28 | O RING 25/606836 | 1 | $2.93 | |||
| 29 | SEAL WIPER 25/606835 | 1 | $16.47 | |||
| 31 | SPRING 25/606847 | 1 | $3.43 | |||
| 32 | CAP 25/606846 | 1 | $46.54 | |||
| 33 | SPOOL END 25/606828 | 1 | $23.68 | |||
| 34 | BOLT 25/606101 25/606101A | 1 | $0.71 | |||
| 35 | PLATE SEAL 25/606826 | 1 | $7.45 | |||
| 38 | Plug 332/D5162 | 1 | $2.68 | |||
| A | relief 333/H1995 | 1 | $127.74 | |||
| B | relief 333/H1996 | 1 | $204.41 | |||
| C | Relief valve 334/G9666 | 1 | $205.42 | |||
| D | Relief valve 334/E2133 | 1 | $204.41 | |||
| E | PLUG ASSEMBLY 25/606822 | 1 | $13.39 | |||
| F | PLUG KIT 25/607234 | 1 | $33.44 | |||
Showing 1 to 33 of 33 parts
Related Assemblies
-
DIAG-E340-2-1-394199 E340-2-1 VALVES SERVO CONTROL (PILOT CONTROL) COMPONENTS SECTIONS, 334/U2220
View Diagram -
DIAG-E340-3-1-394199-10650590 E340-3-1 VALVES SERVO CONTROL (PILOT CONTROL) COMPONENTS 334/U2220
View Diagram -
DIAG-E340-1-5-394199 E340-1-5 VALVES SERVO CONTROL (PILOT CONTROL) 10 SPOOL
View Diagram
