Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 10 | PILOT VALVE 400/B1832 401/M8958 | 1 | $979.73 | |||
| 20 | ACCUMULATOR 0.24ltr 5.0ba 401/C8565 | 1 | $216.27 | |||
| 20 | ACCUMULATOR DISCHARGED 903/11150 32/926090 | 1 | $577.56 | |||
| 30 | ADAPTOR 9/16SAE x G3/8A (P980) 816/90271 | 1 | $7.88 | |||
| 40 | ADAPTOR 1620/2052 | 1 | $2.49 | |||
| 50 | ADAPTOR G1/4A-9/16UNF (M) 1620/0002 1620/2051 | 1 | $5.41 | |||
| 60 | 'Adapter Pressure Test Point 9/16-18UNF 45/908000 | 1 | $132.58 | |||
| 70 | ELBOW G1/4A X 9/16UNF 816/90618 | 1 | $21.13 | |||
| 80 | PILOT VALVE BRACKET 400/Y6366 | 1 | $18.00 | |||
| 90 | WASHER M_8 PLAIN 1420/0007Z 1420/0007D | 1 | $0.20 | |||
| 100 | SET-SCREW M_8 L-_16mm 1315/0303D | 1 | $0.86 | |||
Showing 1 to 11 of 11 parts
Related Assemblies
-
DIAG-E340-1-5-401621 E340-1-5 VALVES SERVO CONTROL (PILOT CONTROL) INSTALLATION PILOT VALVE
View Diagram -
DIAG-E310-110-1-401621 E310-110-1 VALVES LOADER OUTLET SECTION COMPONENTS
View Diagram -
DIAG-E340-1-10-401621 E340-1-10 VALVES SERVO CONTROL (PILOT CONTROL) INSTALLATION PILOT VALVE
View Diagram
