| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | SWAY VALVE BRACKET 333/C1834 | 1 | $48.67 | |||
| 2 | SWAY VALVE 332/H5331 | 1 | $1,339.25 | |||
| 3 | (W) SET SCREW M8x40 1315/0310Z | 1 | $1.55 | |||
| 4 | WASHER M_8 SPRING 1425/0007Z | 1 | $1.22 | |||
| 5 | WASHER M_8 PLAIN 1420/0007Z 1420/0007D | 1 | $0.20 | |||
| 6 | SET-SCREW M10 L-_30mm 1315/0408Z | 1 | $1.22 | |||
| 7 | WASHER M10 PLAIN 1425/0008Z 1420/0008D | 1 | $0.23 | |||
| 9 | ADAPTOR G1/4A-7/16UNF(M) 1620/2050 | 1 | $2.60 | |||
| 10 | ADAPTOR G5/8A x 3/4 SAE 816/90007 | 1 | $21.93 | |||
| 11 | 1/4BSP-7/16SAE RESTRCITOR 816/91034 | 1 | $43.21 | |||
| 12 | ADAPTOR G1/2A X 3/4 SAE 1620/2066 | 1 | $30.60 | |||
Showing 1 to 11 of 11 parts
Related Assemblies
-
DIAG-E300-10-1-402739 E300-10-1 VALVE INSTALLATION ASSEMBLIES DIVERTER VALVE
View Diagram -
DIAG-E190-140-1-402739 E190-140-1 OTHER HYDRAULIC CIRCUITS HYDRAULIC PIN LOCK CARRIAGE HYDRAULICS
View Diagram -
DIAG-E190-135-1-402739 E190-135-1 OTHER HYDRAULIC CIRCUITS HYDRAULIC PIN LOCK SINGLE PIN DOUBLE ACTING VALVE
View Diagram
