E3-5-1 VALVE, SECTION Parts Diagram | JCB | Scholten’s Equipment

Scroll to zoom Click a part # to view details

Ref #	Part Number	Qty.	Avl.	Price (USD)	Action
1	CAP-DETENT 25/608608	1	AVAILABLE TO ORDER	$243.07	Quantity
3	SEAT SPRING 25/608609	1	AVAILABLE TO ORDER	$14.10	Quantity
4	O RING 25/608606	1	AVAILABLE TO ORDER	$7.99	Quantity
5	CAPSCREW 25/608607	1	AVAILABLE TO ORDER	$38.39	Quantity
6	SOLENOID AMP CONNE 25/621702	1	AVAILABLE TO ORDER	$1,234.20	Quantity
7	SEAL 25/611412	1	AVAILABLE TO ORDER	$0.89	Quantity
9	SPACER 25/611410	1	AVAILABLE TO ORDER	$80.70	Quantity

Showing 1 to 7 of 7 parts
