Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| SPOOL 25/221948 | 1 | $1,018.09 | ||||
| VALVE ASSEMBLY 4 S 25/213700 | 1 | $22,748.31 | ||||
| 1 | KIT-5 SECTION 998/10402 | 1 | $1,254.10 | |||
| 2 | BODY ASSY 25/202801 | 1 | $3,309.01 | |||
| 3 | Plug with seal 25/222091 | 1 | $78.35 | |||
| 4 | VALVE - ATB 25/221558 | 1 | $850.46 | |||
| 4A | KIT-SEAL 25/222160 | 1 | $411.76 | |||
| 5 | VALVE SECTION PRIO 25/220594 | 1 | $4,753.63 | |||
| 6 | VALVE, SECTION - LIFT 25/220595 | 1 | $10,785.30 | |||
| 7 | VALVE ANTI CAV - ATB 25/976704 | 1 | $1,396.14 | |||
| 7A | KIT - ATB 25/222116 | 1 | $480.13 | |||
| 8 | VALVE RELIEF 5050 - ATB 25/977706 | 1 | $1,876.85 | |||
| 10 | SPOOL 25/221186 | 1 | $990.90 | |||
| 11 | SPRING -ATB 814/10001 | 1 | $35.89 | |||
| 12 | HOUSING 25/220596 | 1 | $796.09 | |||
| 13 | VALVE - ATB 25/997204 25/221564 | 1 | $352.33 | |||
| 14 | BALL - ATB 25/971201 | 1 | $52.08 | |||
| 15 | Plug expansion 25/971233 | 1 | $52.45 | |||
| 16 | HOUSING ACTUATOR 25/971264 25/222161 | 1 | $280.38 | |||
| 17 | CAPSCREW SOCKET HE 25/222162 | 1 | $56.90 | |||
| 18 | CAPSCREW 25/222163 | 1 | $56.02 | |||
| 19 | WASHER 25/971247 | 1 | $27.04 | |||
| 20 | NUT 25/971244 | 1 | $6.66 | |||
| 21 | RETAINER - ATB 25/221843 | 1 | $131.11 | |||
| 22 | SPRING 25/221177 | 1 | $35.53 | |||
| 23 | STUD SPOOL 25/222118 | 1 | $352.26 | |||
| 24 | RETAINER SPRING 25/971242 | 1 | $70.22 | |||
| 25 | RETAINER - ATB 25/222119 | 1 | $212.05 | |||
| 26 | SPRING -ATB 25/971265 | 1 | $65.12 | |||
| 27 | SPACER 25/222120 | 1 | $381.59 | |||
| 28 | RETAINER 25/971216 | 1 | $80.61 | |||
| 29 | HOUSING - ATB 25/971261 25/222164 | 1 | $997.47 | |||
| 30 | VALVE SECTION BUCK 25/201901 | 1 | $8,972.87 | |||
| 31 | VALVE RELIEF 1800 - ATB 25/201902 | 1 | $1,876.85 | |||
| 31A | KIT -SEAL - ATB 25/976601 | 1 | $204.73 | |||
| 32 | AUXILIARY RELIEF VALVE 25/997709 25/201101 | 1 | $1,408.68 | |||
| 33 | PLUG - ATB 25/222092 | 1 | $32.60 | |||
| 34 | SPOOL ATB 25/221303 | 1 | $508.34 | |||
| 35 | SPRING 25/221178 | 1 | $80.59 | |||
| 36 | SPRING -ATB 25/221179 | 1 | $61.36 | |||
| 37 | Valve shuttle 25/997219 25/220853 | 1 | $686.30 | |||
| 42 | SCREW 25/971246 | 1 | $1.05 | |||
| 48 | Stud spool connect 25/222122 | 1 | $141.18 | |||
| 50 | VALVE SECTION AUXILLARY 25/994200 | 1 | $5,873.73 | |||
| 51 | PLUG 25/971254 | 1 | $195.88 | |||
| 53 | Unit regulating 25/222303 | 1 | $189.43 | |||
| 64 | SPRING -ATB 25/222121 | 1 | $89.80 | |||
| 89 | COVER END C/W PRES. 25/220593 | 1 | $2,536.37 | |||
| 90 | Plug c/w O Ring - ATB 25/971230 | 1 | $75.41 | |||
| 91 | SPRING 25/971213 | 1 | $88.23 | |||
| 92 | SCREW CAP 25/971231 | 1 | $42.34 | |||
| 93 | WASHER ATB 25/971212 | 1 | $62.08 | |||
| 94 | SPOOL REGULATOR - ATB 25/971232 | 1 | $117.22 | |||
| 96A | KIT SEAL BETWEEN S 998/10280 | 1 | $591.13 | |||
| 96B | KIT-SEAL 25/987605 | 1 | $95.85 | |||
| 96C | KIT SEALING 998/10404 | 1 | $1,196.02 | |||
| 96D | KIT-SEAL - ATB 25/202001 | 1 | $996.73 | |||
| 96F | KIT-END COVER 25/987606 | 1 | $410.90 | |||
Showing 1 to 58 of 58 parts
