| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | LOADER VALVE 3sp dtent reset 25/222580 332/H4081 | 1 | $4,709.67 | |||
| 4 | Kit Spool and Asse 25/222844 | 1 | $393.12 | |||
| 6 | Spacer 25/222843 | 1 | $57.76 | |||
| 7 | Sleeve 25/222842 | 1 | $161.62 | |||
| 10 | Screw 25/974622 333/Y0839 | 1 | $5.75 | |||
| 11 | Plate seal 25/222674 | 1 | $10.23 | |||
| 12 | Retainer 25/974615 | 1 | $10.85 | |||
| 13 | Spacer 25/222675 | 1 | $14.46 | |||
| 14 | Spring 25/974619 | 1 | $5.82 | |||
| 15 | SEAT SPRING 25/608201 | 1 | $35.44 | |||
| 16 | PLATE-SEAL 25/975702 | 1 | $13.26 | |||
| 17 | SEAL 25/221208 | 1 | $38.59 | |||
| 18 | KIT SPOOL END 25/221151 | 1 | $647.53 | |||
| 19 | Screw Soc. HD cap 25/222840 | 1 | $9.52 | |||
| 20 | COIL 12V 25/221152 | 1 | $389.47 | |||
| 21 | CLIP 25/221153 | 1 | $15.44 | |||
| 23 | Circlip 25/222839 | 1 | $30.23 | |||
| 24 | Spacer clapper 25/222838 | 1 | $65.58 | |||
| 25 | Spacer spool end 25/222837 | 1 | $32.17 | |||
| 26 | Plate seal 25/222836 | 1 | $9.35 | |||
| 28 | Spacer 25/222835 | 1 | $27.96 | |||
| 29 | SPRING 25/606501 | 1 | $4.45 | |||
| 33 | Kit spool end assy 25/222412 | 1 | $349.04 | |||
| 35 | COVER 25/222199 25/606108 | 1 | $28.26 | |||
| 36 | Sleeve 25/222672 | 1 | $41.91 | |||
| 37 | BALL 5MM DIA 25/974621 | 1 | $6.87 | |||
| 38 | Cap Spool end 25/222673 | 1 | $122.39 | |||
| 46 | Kit Std Spool Glan 25/221140 25/222660 | 1 | $36.81 | |||
| 48 | BOLT 25/606101 25/606101A | 1 | $0.71 | |||
| 49 | PLATE, SEAL 25/222198 | 1 | $7.45 | |||
| 50 | WIPER SEAL 25/222661 | 1 | $48.55 | |||
| 52 | Kit float spool gl 25/222669 | 1 | $75.16 | |||
| 53 | SCREW 25/606839 | 1 | $0.71 | |||
| 57 | SPACER 25/974609 | 1 | $9.52 | |||
| 59 | HOUSING 25/974608 | 1 | $11.19 | |||
| 60 | O RING 25/974607 | 1 | $8.36 | |||
| 61 | PLUG 25/974631 | 1 | $49.98 | |||
| 63 | Spring 25/974629 | 1 | $9.52 | |||
| 64 | PLUG KIT 25/222414 | 1 | $85.66 | |||
| 67 | KIT 25/221746 | 1 | $50.57 | |||
| 70 | SOLENOID ASSEMBLY 25/222657 | 1 | $802.96 | |||
| 71 | NUT COIL RETAINER 25/222826 | 1 | $1.97 | |||
| 74 | COIL 12V SOLENOID 332/G9415 25/222658 | 1 | $109.23 | |||
| 75 | KIT-SEAL 25/974640 | 1 | $4.51 | |||
| 91 | VALVE RELIEF 25/222659 25/618901 | 1 | $241.11 | |||
| 91A | KIT-REPAIR RELIEF 25/618902 | 1 | $61.39 | |||
| 92 | Kit unloading pilo 25/222834 | 1 | $338.94 | |||
| 92A | KIT-SEAL 25/974633 | 1 | $36.15 | |||
| 93 | RELIEF VALVE 172 bar 25/222415 333/C8654 | 1 | $346.98 | |||
| 93A | SEAL 25/222305 | 1 | $43.04 | |||
| 94 | RELIEF VALVE 310 bar 25/222416 333/C8658 | 1 | $347.12 | |||
Showing 1 to 51 of 51 parts
