Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 10 | 1/4 BSP HOSE 1270m 611/20100 332/G2540 | 1 | $95.77 | |||
| 20 | PVC SLEEVE - 900MM 647/02711 647/02729 | 1 | $10.98 | |||
| 30 | WA HOSE GUIDE 400/N1742 | 1 | $19.24 | |||
| 40 | WA SHROUD BRACKET 400/L9199 | 1 | $45.92 | |||
| 50 | WASHER M_8 PLAIN 1420/0007Z 1420/0007D | 1 | $0.20 | |||
| 60 | SETSCREW M8x35 1315/0309D | 1 | $2.40 | |||
| 70 | NUT M8 STD SELF LOCK 1370/0203D | 1 | $1.75 | |||
| 80 | RAM - HYD PIN LOCKING 401/L0100 | 1 | $405.05 | |||
| 90 | WASHER M10 PLAIN 1425/0008Z 1420/0008D | 1 | $0.23 | |||
| 100 | BOLT M10x75 1315/3417D | 1 | $2.56 | |||
| 110 | NUT M10 STD SELF LOCK 1370/0303Z 1370/0303D | 1 | $0.65 | |||
| 120 | ELBOW G1/4A X 9/16UNF 816/90618 | 1 | $21.13 | |||
| 130 | ADAPTOR G1/4A-9/16UNF (M) 1620/0002 1620/2051 | 1 | $5.41 | |||
| 140 | LEVER WA (LOCKING) HYD PIN 400/M7979 | 1 | $107.10 | |||
| 150 | CLEVIS PIN 913/00012 | 1 | $21.95 | |||
Showing 1 to 15 of 15 parts
Related Assemblies
-
DIAG-E190-130-1-402885 E190-130-1 OTHER HYDRAULIC CIRCUITS HYDRAULIC PIN LOCK DOUBLE PIN DOUBLE ACTING VALVE
View Diagram -
DIAG-E190-130-5-402885 E190-130-5 OTHER HYDRAULIC CIRCUITS HYDRAULIC PIN LOCK DOUBLE PIN DOUBLE ACTING VALVE
View Diagram -
DIAG-E190-375-1-402885 E190-375-1 OTHER HYDRAULIC CIRCUITS HYDRAULIC PIN LOCK SINGLE PIN DOUBLE ACTING VALVE
View Diagram
