Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | BALL VALVE 25/222123 | 1 | $576.49 | |||
| 2 | 1.1/16 - 7/8UNF BULKHEAD ADAPTOR 333/R2137 | 1 | $44.19 | |||
| 3 | QRC 12 FEMALE - 12 SAE 45/920047 | 1 | $194.17 | |||
| 4 | DIPPER LH C/O BRKT 333/U4700 | 1 | $102.75 | |||
| 5 | COUPLING QR MALE HQ12 - 12SAE 45/920048 | 1 | $58.34 | |||
| 6 | DIPPER AUX RETURN BRKT 333/V1044 | 1 | $94.74 | |||
| 7 | ADA ORFS M-06/F-06 SWIVEL END 1710/0606 | 1 | $50.31 | |||
| 9 | HOSE -6 ORFS HP 380mm B 334/R0609 | 1 | $54.76 | |||
| 10 | HOSE -6 ORFS HP 3250mm A 334/R0774 | 1 | $183.83 | |||
| 11 | HOSE -6 ORFS HP 3250mm A 334/R0782 | 1 | $183.83 | |||
| 12 | HOSE -6 ORFS HP 380mm B 334/R0644 | 1 | $54.76 | |||
| 13 | ADAPTOR ORFS M -06 /SAE ORB -10 1751/1006 | 1 | $11.22 | |||
| 17 | LABEL - BUCKET C/O 333/V3544 | 1 | $1.79 | |||
| 18 | LABEL - BUCKET C/O - LHS 333/V3627 | 1 | $1.79 | |||
Showing 1 to 14 of 14 parts
