E130-410-1 HYDRAULIC CIRCUITS CHASSIS LOW FLOW CHANGEOVER VALVE TO KINGPOST FOR EXTRADIG EXTENDING DIPPER Parts Diagram | JCB

Scroll to zoom Click a part # to view details

Ref #	Part Number	Qty.	Avl.	Price (USD)	Action
1	ADAPTOR G1/2A X 7/8 SAE (P564) 1620/2055	1	2 IN STOCK	$4.51	Quantity
2	ADAPTOR 7/8SAE x G1/2A 816/90231	1	AVAILABLE TO ORDER	$78.76	Quantity
3	ABI HOSE 1/2 BSP HP 1720B 334/F2240	1	AVAILABLE TO ORDER	$104.69	Quantity
4	ABI HOSE 1/2 BSP HP 1960B SLEEVE 332/H4253	1	AVAILABLE TO ORDER	$166.99	Quantity

Showing 1 to 4 of 4 parts
