Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | ACCUMULATOR 0.24ltr discharged 333/C4920 | 1 | $615.90 | |||
| 1 | PILOT MANIFOLD 332/F8176 | 1 | $2,977.30 | |||
| 2 | HPA MINI FILTER 32/925768 | 1 | $508.38 | |||
| 3 | MOUNT pilot line filter 332/E6556 | 1 | $23.47 | |||
| 4 | Adapter 1"BSP x 1/ 816/90753 | 1 | $27.29 | |||
| 5 | (W) (P) Q/R COUPLING 9/16 332/C0191 | 1 | $54.58 | |||
| 6 | HOSE - 08 BSP LP 1350mm A 332/E7555 | 1 | $51.92 | |||
| 7 | SET-SCREW M10 L-_30mm 1315/0408Z | 1 | $1.22 | |||
| 8 | WASHER M_6 PLAIN 1420/0006Z 1420/0006D | 1 | $0.42 | |||
| 9 | SET SCREW M6 X 16 GRADE 8.8 1315/0203Z 1315/0203D | 1 | $0.54 | |||
| 10 | PLAIN WASHER M10 823/00326 | 1 | $1.78 | |||
| 11 | ADAPTOR G1/4A-9/16UNF (M) 1620/0002 1620/2051 | 1 | $5.41 | |||
| 12 | RIVET NUT M10 826/01249 | 1 | $8.20 | |||
| 13 | SET SCREW M8x30(KANBAN) 1315/0308Z | 1 | $2.17 | |||
| 14 | WASHER M_8 PLAIN 1420/0007Z 1420/0007D | 1 | $0.20 | |||
| 15 | Hose 1/4"BSP 320mm 611/80262 | 1 | $244.06 | |||
| 16 | HOSE 1/4BSP 530mm 611/29300 | 1 | $38.14 | |||
| 17 | ADAPTOR 1620/2052 | 1 | $2.49 | |||
| 18 | RIVET NUT M8 826/01254 826/01106 | 1 | $1.04 | |||
| 19 | SPACER 10.6x22x35 829/31257 | 1 | $1.16 | |||
| 20 | BOLT M8x120 1315/3322Z | 1 | $4.11 | |||
| 21 | P-CLIP 20 I/D 332/C5679 | 1 | $5.61 | |||
| 22 | TEE ADAPTOR MALE RUNNING (P960) 816/90669 | 1 | $18.57 | |||
| 23 | ADAPTOR G1/2A-3/4UNF(M) 1620/2054 | 1 | $37.26 | |||
| 24 | 'Adapter Pressure Test Point 9/16-18UNF 45/908000 | 1 | $132.58 | |||
| 25 | HOSE 612/35300 | 1 | $47.04 | |||
Showing 1 to 26 of 26 parts
Related Assemblies
-
DIAG-E130-33-1-394842 E130-33-1 HYDRAULIC CIRCUITS CHASSIS POWERED SIDESHIFT FIXED DIPPER
View Diagram -
DIAG-E130-27-3-394842 E130-27-3 HYDRAULIC CIRCUITS CHASSIS HIGH FLOW 3/4 HAMMER RETURN
View Diagram -
DIAG-E130-26-4-394842 E130-26-4 HYDRAULIC CIRCUITS CHASSIS HIGH FLOW 3/4 HAMMER FEED
View Diagram
