Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | HOSE -10 BSP HP 1860mm A 34AG/AA186 | 1 | $157.80 | |||
| 2 | HOSE -10 BSP HP 1100mm A 34AG/AA110 | 1 | $95.10 | |||
| 4 | HOSE -04 BSP HP 3800mm B 31AG/BA380 | 1 | $136.02 | |||
| 5 | HOSE 611/47600 | 1 | $60.27 | |||
| 6 | HOSE 04 BSP HP 820mm B 333/P7936 | 1 | $42.03 | |||
| 7 | HOSE -12 BSP HP 1320mm C 333/F5865 | 1 | $405.19 | |||
| 8 | HOSE -10 BSP HP 650mm B 34AG/BA065 | 1 | $96.13 | |||
| 9 | HOSE -06 BSP HP 1600mm B 32AG/BA160 | 1 | $80.80 | |||
| 10 | HOSE 3/8BSP 790mm 612/80378 | 1 | $68.00 | |||
| 11 | Hose 1/4BSP x 920m 611/80210 | 1 | $86.31 | |||
| 12 | HOSE 1/2BSP 680mm 613/27800 | 1 | $106.52 | |||
| 14 | FLANGE SPLIT KRJ2682 | 1 | $18.47 | |||
| 15 | CAP SCREW M10x35 (P960) 1391/3409D | 1 | $4.90 | |||
| 16 | SPRING-WASHER M10 1425/0008D | 1 | $0.44 | |||
| 17 | O-RING - 32.51 x 3.81 PU9 828/00417 828/00021 | 1 | $25.21 | |||
| 18 | ADAPTER TEE M/F/M (R) 816/90079 | 1 | $92.85 | |||
| 19 | ADAPTOR G5/8A-1-1/16UNF(M) 1620/0008 1620/2057 | 1 | $25.23 | |||
| 20 | ADAPTOR 3/8BSPx3/4SAE 1620/2053 | 1 | $2.85 | |||
| 22 | ADAPTOR G1/4A-3/4UNF(M) (R) 1620/2063 | 1 | $4.62 | |||
| 23 | (W) (Pre-P) ADAPTOR -TEE 816/90277 | 1 | $126.10 | |||
| 24 | (W) (P) ADAPTOR G5/8A x G5/8A 816/90339 | 1 | $30.50 | |||
Showing 1 to 21 of 21 parts
Related Assemblies
-
DIAG-E130-10-1-402897 E130-10-1 HYDRAULIC CIRCUITS CHASSIS HOSES & FITTINGS CHASSIS TO BOOM
View Diagram -
DIAG-E130-17-1-402897 E130-17-1 HYDRAULIC CIRCUITS CHASSIS NEUTRAL CIRCUIT
View Diagram -
DIAG-E130-5-1-402897 E130-5-1 HYDRAULIC CIRCUITS CHASSIS SUCTION HOSE INSTALATION
View Diagram
