Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | ADAPTOR ELBOW 816/90594 | 1 | $169.51 | |||
| 2 | ADAP ELBOW 3/4 816/90163 | 1 | $18.47 | |||
| 3 | TWIN BULKHEAD BRACKET 332/G0301 | 1 | $157.48 | |||
| 4 | BACK NUT 3/4"BSP 1356/0206Z | 1 | $7.18 | |||
| 5 | WASHER 1" INT LOCK 1418/0019Z | 1 | $1.97 | |||
| 6 | HAMMER RETURN PIPE 335/10972 | 1 | $68.55 | |||
| 7 | PIPE (kitting) 123/08063 333/F5150 | 1 | $166.87 | |||
| 8 | NUT M12 STD SELF LOCK 1370/0403Z | 1 | $2.11 | |||
| 9 | WASHER M12 PLAIN(KANBAN) 1420/0009Z | 1 | $0.65 | |||
| 10 | ABI HOSE 3/4 BSP HP 2400B SLEEVE 332/H4209 | 1 | $313.23 | |||
| 11 | ABI HOSE 3/4 BSP HP 940B SLEEVE 332/H4304 | 1 | $220.03 | |||
Showing 1 to 11 of 11 parts
Related Assemblies
-
DIAG-E130-119-1-394843 E130-119-1 HYDRAULIC CIRCUITS CHASSIS LOW FLOW RETURN, BI-DIRECTIONAL
View Diagram -
DIAG-E130-117-2-394843 E130-117-2 HYDRAULIC CIRCUITS CHASSIS CHANGEOVER VALVE TO AUXILIARY VALVE, TWIN BI-DIRECTIONAL
View Diagram -
DIAG-E130-131-5-394843 E130-131-5 HYDRAULIC CIRCUITS CHASSIS COOLER FEED, BI-DIRECTIONAL ADVANCED EASYCONTROL
View Diagram
