Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 3 | ADAPTOR TEST POINT G3/4 816/90426 | 1 | $42.62 | |||
| 4 | ADAPTOR G3/4A X 7/8 SAE 1620/2058 | 1 | $5.52 | |||
| 6 | HOSE -12 BSP HP 1760 mm B 335/G6741 | 1 | $143.82 | |||
| 7 | ADAPTOR 7/8 SAE x G3/4A (P564) 332/D6643 | 1 | $19.09 | |||
| 8 | DUAL HOSE CLAMP 332/G7435 | 1 | $3.91 | |||
| 9 | RIVET NUT M10 826/01249 | 1 | $8.20 | |||
| 10 | BOLT M10x70 1315/3416Z | 1 | $4.90 | |||
| 12 | PLAIN WASHER M10 823/00326 | 1 | $1.78 | |||
| 13 | ADAPTOR G3/4A-1-1/16UNF(M 1620/0010 1620/2059 | 1 | $14.30 | |||
| 14 | WASHER M10 PLAIN 1425/0008Z 1420/0008D | 1 | $0.23 | |||
| 15 | HOSE -12 BSP HP 1760 mm A 336/E3976 | 1 | $195.55 | |||
| 16 | ADAPTOR 1-1/6SAE x G3/4 816/90489 | 1 | $11.19 | |||
Showing 1 to 12 of 12 parts
Related Assemblies
-
DIAG-E120-20-1-394763 E120-20-1 HYDRAULIC CIRCUITS LOADER END CONTROL, LOADER ARM,2 SPOOL
View Diagram -
DIAG-E120-65-1-394763 E120-65-1 HYDRAULIC CIRCUITS LOADER END BLANKING, 3 SPOOL
View Diagram -
DIAG-E120-15-1-394763 E120-15-1 HYDRAULIC CIRCUITS LOADER END LIFT RAM
View Diagram
