Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | WA AUX ARM PIPEWORK 335/08589 | 1 | $265.67 | |||
| 2 | HOSE ASSY 615/80025 | 1 | $106.77 | |||
| 3 | ADAPTER 816/10159 | 1 | $25.45 | |||
| 4 | BOLT M10x80 1315/3418D | 1 | $2.43 | |||
| 5 | (S) CAP - 3/4"BSP 816/00196 | 1 | $37.26 | |||
| 6 | WASHER M10 PLAIN 1425/0008Z 1420/0008D | 1 | $0.23 | |||
| 7 | NUT M10 STD SELF LOCK 1370/0303Z 1370/0303D | 1 | $0.65 | |||
| 8 | HOSE 3/4BSP 780mm 615/27500 | 1 | $109.79 | |||
Showing 1 to 8 of 8 parts
Related Assemblies
-
DIAG-E120-9-1-404971 E120-9-1 HYDRAULIC CIRCUITS LOADER END AUXILIARY 3RD SPOOL ZX
View Diagram -
DIAG-E190-1-1-404971 E190-1-1 OTHER HYDRAULIC CIRCUITS SUCTION HOSE
View Diagram -
DIAG-E120-8-1-404971 E120-8-1 HYDRAULIC CIRCUITS LOADER END AUXILIARY 4TH SPOOL, SHL, HT
View Diagram
