Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 10 | SET-SCREW M_6 L-_20mm(KANBAN) 1315/0205Z | 1 | $0.33 | |||
| 20 | BOLT M8x35 1315/3309Z | 1 | $1.97 | |||
| 30 | BOLT M8x70 1315/3316Z | 1 | $2.18 | |||
| 40 | NUT M_8 STD SELF LOCK(KANBAN) 1370/0203Z | 1 | $6.63 | |||
| 50 | WASHER M_8 PLAIN 1420/0007Z 1420/0007D | 1 | $0.00 | |||
| 60 | (W) M6 HARDENED WASHER 1422/0006D | 1 | $2.28 | |||
| 100 | ADAPTOR 3/8BSPx3/4SAE 1620/2053 | 1 | $2.85 | |||
| 110 | 90 DEG ELBOW M/F 816/90076 | 1 | $45.04 | |||
| 120 | COVER PLATE and bolt 821/00169 821/00169A | 1 | $1.92 | |||
| 130 | CLAMP COVER PLATE 821/00335 | 1 | $8.08 | |||
| 140 | TWIN CLAMP MOULDING 821/00347 | 1 | $31.20 | |||
| 150 | Hose 478/00632 | 1 | $250.62 | |||
| 160 | HOSE 1/2BSP 720mm 613/80327 | 1 | $39.22 | |||
| 170 | HOSE 1/2BSP HP 750MM LONG 633/80034 | 1 | $66.60 | |||
| 180 | HP 3/8BSP x 1820 mmLG 612/80369 | 1 | $119.81 | |||
| 190 | HOSE 3/8BSP 2600mm 612/80411 | 1 | $59.30 | |||
| 200 | HOSE 3/8BSP 790mm 612/26700 | 1 | $46.51 | |||
| 220 | SET SCREW M10x45 1315/0411Z | 1 | $1.46 | |||
| 230 | WASHER M10 PLAIN 1425/0008Z 1420/0008D | 1 | $0.00 | |||
Showing 1 to 19 of 19 parts
Related Assemblies
-
DIAG-E100-95-1-401598 E100-95-1 HYDRAULIC CIRCUIT INSTALLATION ASSEMBLIES
View Diagram -
DIAG-E190-240-1-401598 E190-240-1 OTHER HYDRAULIC CIRCUITS REAR AUXILIARY COUPLING
View Diagram -
DIAG-E190-245-1-401598 E190-245-1 OTHER HYDRAULIC CIRCUITS REAR AUXILIARY
View Diagram
