Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | STEER VALVE + SHOCKS (N) 403-7424-78 332/D4864 | 1 | $1,090.67 | |||
| 2 | ADAPTOR 3/8BSPx3/4SAE 1620/2053 | 1 | $2.85 | |||
| 3 | ADAPTOR G3/8Ax3/4 SAE 1620/2067 | 1 | $32.96 | |||
| 4 | ADAPTOR G1/4A-7/16UNF(M) 1620/2050 | 1 | $2.60 | |||
| 6 | WASHER 7/16 LARGE 1412/0004D | 1 | $2.75 | |||
| 7 | BOLT M10x35 1315/3409D | 1 | $8.02 | |||
| 8 | RESILIENT MOUNT 141/00936 | 1 | $17.97 | |||
| 9 | STEERING VALVE SPACER (P493) 400/C4670 | 1 | $19.46 | |||
| 10 | ORBITROL VALVE - SEAL (P493) 334/F6757 | 1 | $10.30 | |||
| 11 | (P) HOSE 3/8 BSP HP 440B (LDL MIXED) 32AG/BA044 | 1 | $56.59 | |||
| 11 | (W) (P) HOSE -6 BSP HP 460mm B (P493) 400/G8548 | 1 | $113.15 | |||
| 12 | (W) (P) HOSE -6 BSP HP 420mm B (P493) 400/G8357 | 1 | $127.33 | |||
| 13 | HOSE -06 BSP HP 480mm B (P493D) 32AG/BA048 | 1 | $61.42 | |||
| 14 | (P) HOSE -6 BSP HP 440mm B (P493) 400/G8602 | 1 | $97.05 | |||
| 15 | '(W) (P) HOSE -04 QLD/BSP HP 600mm (P493 400/W8758 | 1 | $119.25 | |||
| 15 | HOSE -04 BSP HP 560mm B (P493D) 31AG/BA056 | 1 | $56.31 | |||
| 16 | STEERING SHAFT REDUCED 402/T2913 | 1 | $50.38 | |||
| 17 | FLEXIBLE COUPLING 331/36009 | 1 | $161.48 | |||
| 18 | COLUMN RETAINER PLATE (P493) 400/C4748 | 1 | $13.63 | |||
| 19 | CIRCLIP - OPTIMAS PART! Line side 821/00190 | 1 | $0.54 | |||
| 20 | SET-SCREW M_8 L-_40mm 1315/0310D | 1 | $17.79 | |||
| 21 | NUT M8 STD SELF LOCK 1370/0203D | 1 | $1.75 | |||
Showing 1 to 22 of 22 parts
