Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| (W) SET SCREW M8x40 1315/0310Z | 1 | $1.55 | ||||
| COUPLING QR FEMALE A13 - 3/4BSP 45/908400 | 1 | $167.30 | ||||
| COUPLING QR MALE F13 - 3/4BSP 45/910300 | 1 | $125.84 | ||||
| NUT M_8 STD SELF LOCK(KANBAN) 1370/0203Z | 1 | $0.26 | ||||
| PIPE AUX 335/02805 | 1 | $260.70 | ||||
| PIPE AUX 335/02806 | 1 | $803.28 | ||||
| SET SCREW M8x30(KANBAN) 1315/0308Z | 1 | $2.17 | ||||
| WASHER BONDED 1" BSP 1406/0021 | 1 | $6.00 | ||||
| 1 | AUX PIPE LOWER 335/04690 | 1 | $323.84 | |||
| 2 | AUX PIPE UPPER 335/04689 | 1 | $241.04 | |||
| 2 | WA AUX PIPE UPPER 335/08810 | 1 | $553.30 | |||
| 3 | PIPE SUPP.BRKT.ZINC PLTD. 331/24340 | 1 | $140.18 | |||
| 5 | COUPLING QR MALE HQ12 - 12SAE 45/920048 | 1 | $58.34 | |||
| 6 | QRC 12 FEMALE - 12 SAE 45/920047 | 1 | $194.17 | |||
| 8 | ADAPTOR G5/8Ax7/8SAE 1620/0007 1620/2056 | 1 | $12.58 | |||
| 9 | SET-SCREW M_8 L-_40mm 1315/0310D | 1 | $17.79 | |||
| 10 | NUT M8 STD SELF LOCK 1370/0203D | 1 | $1.75 | |||
| 11 | WASHER M_8 PLAIN 1420/0007Z 1420/0007D | 1 | $0.20 | |||
| 12 | HOSE.5/8BSP 4360 lg 614/80048 | 1 | $156.13 | |||
| 14 | ADAPTOR 5/8BSP 816/90207 | 1 | $19.27 | |||
| 14A | 'O' RING (P564) 2401/0507 | 1 | $1.46 | |||
| 15 | SET-SCREW M_8 L-_30mm 1315/0308D | 1 | $1.63 | |||
| 16 | HOSE 5/8BSP 4360mm 614/80053 | 1 | $427.33 | |||
Showing 1 to 23 of 23 parts
Related Assemblies
-
DIAG-E1-5-1-395428 E1-5-1 HOSE AND PIPEWORK SERVO CONTROLLER TRANSMISSION (LEFT HAND)
View Diagram -
DIAG-D2-2-2-395428 D2-2-2 CONTROL, THROTTLE HAND AND FOOT
View Diagram -
DIAG-D2-2-1-395428 D2-2-1 CONTROL, THROTTLE HAND AND FOOT
View Diagram
