Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| HOSE 1/4BSP 610mm 611/21200 | 1 | $41.69 | ||||
| 1 | 'STEER VLVE 740 CC/REV 446 (233-4057-003 35/910105 | 1 | $3,705.40 | |||
| 1 | VALVE STEER - ATB 35/902100 | 1 | $5,020.20 | |||
| 2 | ADAPTOR G1/2A-3/4UNF(M) 1620/2054 | 1 | $37.26 | |||
| 2A | O-RING 2401/0506 | 1 | $1.46 | |||
| 3 | ADAPTOR G1/4A-7/16UNF(M) 1620/2050 | 1 | $2.60 | |||
| 3 | ELBOW G1/4A X 9/16UNF 816/90618 | 1 | $21.13 | |||
| 3A | O-RING 2401/0503 | 1 | $0.54 | |||
| 6 | HOSE 1/2BSP 2080mm 613/80181 | 1 | $78.39 | |||
| 25 | HOSE 1/2BSP 1800mm 613/29700 | 1 | $192.51 | |||
| 28 | T ADAPTOR WA 426/36 335/11104 | 1 | $66.66 | |||
| 29 | SETSCREW M8x35 1315/0309D | 1 | $2.40 | |||
| 30 | WASHER M_8 PLAIN 1420/0007Z 1420/0007D | 1 | $0.00 | |||
| 31 | NUT M8 STD SELF LOCK 1370/0203D | 1 | $6.15 | |||
| 36 | ADAPTOR 1/4 BSP BULKHEAD 816/90005 | 1 | $4.45 | |||
| 38 | Hose "SLS" 269/40962 | 1 | $122.71 | |||
| 39 | HOSE 1/2BSP 1300mm 629/80093 | 1 | $80.62 | |||
Showing 1 to 17 of 17 parts
Related Assemblies
-
DIAG-E1-19-1-404839-15769683 E1-19-1 FILTER, HYDRAULIC RETURN PIPE
