Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 10 | AUX HOSE BRACKET 333/T9797 | 1 | $40.99 | |||
| 20 | CLAMP COVER PLATE 821/00335 | 1 | $8.08 | |||
| 30 | SET-SCREW M10 L-_25mm 1315/0407D | 1 | $0.62 | |||
| 40 | TWIN CLAMP MOULDING 821/00347 | 1 | $31.20 | |||
| 50 | WASHER M10 PLAIN 1425/0008Z 1420/0008D | 1 | $0.23 | |||
| 60 | NUT M8 STD SELF LOCK 1370/0203D | 1 | $1.75 | |||
| 70 | (W) BOLT M8x80 1315/3318D | 1 | $3.67 | |||
| 80 | WASHER M_8 PLAIN 1420/0007Z 1420/0007D | 1 | $0.20 | |||
| 90 | Adapter 816/90497 | 1 | $43.08 | |||
| 100 | SPACER 191/00456 | 1 | $171.12 | |||
| 110 | SET-SCREW M_8 L-_20mm 1315/0305D | 1 | $10.29 | |||
| 120 | FEED PIPE 655/50082 | 1 | $137.37 | |||
| 140 | ADAPTOR 816/90021 | 1 | $38.21 | |||
| 150 | WASHER 3/8in MEDIUM 1411/0003D | 1 | $0.48 | |||
| 160 | HEX.BOLT M10x40 LG (P664/P545) 1315/3410D | 1 | $1.89 | |||
| 170 | COUPLING QR FEMALE HQ10 - 8SAE 45/920049 | 1 | $160.53 | |||
| 180 | MOUNTING BRACKET SUPPORT 191/00665 | 1 | $383.73 | |||
| 190 | SET SCREW M10x35 1315/0409D | 1 | $10.55 | |||
| 210 | FEED PIPE 655/50081 | 1 | $126.20 | |||
| 220 | REEL HOSE 191/47300 | 1 | $7,756.59 | |||
| 230 | COUPLING QR MALE 10 -8SAE 45/920050 | 1 | $103.37 | |||
| 240 | HOSE 99 3/8 STR/90 612/21400 | 1 | $240.66 | |||
Showing 1 to 22 of 22 parts
Related Assemblies
-
DIAG-E1-14-41-399287 E1-14-41 CIRCUIT, AUXILIARY SINGLE 5.5M TRIPLEX MAST
View Diagram -
DIAG-E1-14-21-399287 E1-14-21 CIRCUIT, AUXILIARY SINGLE 3.6M DUPLEX MAST
View Diagram -
DIAG-E3-9-1-399287 E3-9-1 OTHER VALVES BLANKING KIT VALVE BLOCK
View Diagram
