Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| KIT-SEAL 45/901701 | 1 | $27.07 | ||||
| SEAL KIT 45/901901 | 1 | $14.44 | ||||
| 1 | PIPE CLUSTER 123/74500 | 1 | $4,252.11 | |||
| 2 | HOSE 1/2BSP 2620mm 613/27700 | 1 | $158.72 | |||
| 3 | PIPE 123/58000 | 1 | $1,603.41 | |||
| 4 | HOSE 1/2BSP 1200mm 613/05100 | 1 | $145.40 | |||
| 5 | ADAPTOR-TWIN FEED 123/00524 | 1 | $1,361.84 | |||
| 7 | (P) SET 3/8UNFx1 HT 1305/0206Z | 1 | $2.49 | |||
| 8 | WASHER 3/8" SPRING 1416/0006Z | 1 | $0.45 | |||
| 11 | WASHER BONDED 1" BSP 1406/0021 | 1 | $3.24 | |||
| 13 | FERRULE 830/00314 | 1 | $5.82 | |||
| 15 | BOLT 3/8 X 2 1/4 UNF 1305/3216Z | 1 | $7.17 | |||
| 16 | ADAPTOR G3/4A M/M 1604/0006 | 1 | $12.04 | |||
| 20 | WASHER BONDED 1"BSP 1406/0026 | 1 | $7.06 | |||
| 21 | ADAPTOR G1A M/M 1604/0008 1604/2057 | 1 | $33.09 | |||
| 25 | SPACER PLATE 123/00315 | 1 | $57.95 | |||
| 26 | CLAMP BASE 821/00124 | 1 | $9.55 | |||
| 27 | SEALANT SILICONE 310ML 4102/0933 | 1 | $24.15 | |||
| 28 | CLAMP MOULDING SINGLE 821/00222 | 1 | $83.93 | |||
| 29 | COVER PLATE ASSY 821/00127 | 1 | $11.87 | |||
| 31 | HOSE 39-1/2" 1 ST/ST 617/01900 | 1 | $187.53 | |||
| 32 | PIPE 123/00621 | 1 | $750.98 | |||
| 33 | HOSE 36 1 STR/90 617/21500 | 1 | $215.04 | |||
Showing 1 to 23 of 23 parts
Related Assemblies
-
DIAG-E1-13-2-395100 E1-13-2 CIRCUIT, AUXILIARY BACKHOE, BREAKER PATCH PLANER, STANDARD DIPPER
View Diagram -
DIAG-E1-13-6-395100 E1-13-6 CIRCUIT, AUXILIARY BREAKER RETURN TO TANK, SIDESHIFT
View Diagram -
DIAG-E1-13-8-395100 E1-13-8 CIRCUIT, AUXILIARY BREAKER RETURN TO TANK, SIDESHIFT
View Diagram
