Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | BOLT, FLANGE 01774-51010 | 1 | $2.95 | |||
| 020 | Washer 04717-00100 04717-01000 | 1 | $2.26 | |||
| 030 | CAP 37410-38530 | 1 | $8.74 | |||
| 040 | SEAL, OIL K1253-16370 | 1 | $64.81 | |||
| 050 | BRG BALL RADIAL3 08101-06907 | 1 | $24.06 | |||
| 060 | CIR-CLIP, INTERN 04611-00470 | 1 | $2.93 | |||
| 070 | BRG BALL RADIAL3 08101-06906 | 1 | $15.83 | |||
| 080 | COVER, GEAR CASE K1253-15480 | 1 | $125.15 | |||
| 090 | O-RING 04811-11350 | 1 | $9.28 | |||
| 100 | Flange Bolt 01754-50830 | 1 | $5.85 | |||
| 110 | GEAR, BEVEL F K1253-16280 | 1 | $322.25 | |||
| 120 | SHIM K1253-16610 | 1 | $6.30 | |||
| 120 | SHIM K1253-16620 | 1 | $6.30 | |||
| 120 | SHIM K1253-16630 | 1 | $5.74 | |||
| 120 | SHIM K1253-16640 | 1 | $5.74 | |||
| 120 | SHIM K1253-16650 | 1 | $5.74 | |||
| 130 | BEARING BALL RAD PL501-12120 08101-06202 | 1 | $9.24 | |||
| 140 | SHAFT, BEVEL GEA K1253-16310 | 1 | $108.38 | |||
| 150 | BRG BALL RADIAL1 6A700-16610 08101-06302 | 1 | $12.10 | |||
| 160 | SHAFT, FRONT AXL K1253-16410 | 1 | $137.80 | |||
| 170 | GEAR, BEVEL K1253-16320 | 1 | $322.25 | |||
| 180 | BUSHING (1512) K1253-16430 | 1 | $16.35 | |||
| 190 | Radial Ball Bearing (6204) PL501-12160 08101-06204 | 1 | $12.02 | |||
| 200 | COLLAR, K1253-16420 | 1 | $13.47 | |||
| 210 | SEAL, OIL 45403-51280 | 1 | $14.28 | |||
| 220 | SUPPORT, KINGPIN K1261-15540 | 1 | $93.62 | |||
| 230 | STUD 01555-51025 | 1 | $5.37 | |||
| 240 | Nut (Fastener) 02117-50100 02118-50100 | 1 | $0.80 | |||
| 250 | Spring Washer (Lock Washer) 04512-60100 04512-70100 | 1 | $0.60 | |||
| 260 | PIPE, KINGPIN K1253-16360 | 1 | $36.98 | |||
| 280 | ASSY CASE, GEAR K1253-15400 | 1 | $434.50 | |||
Showing 1 to 31 of 31 parts
Related Assemblies
-
DIAG-E01001-85016 E01001 FRONT AXLE(LEFT)
View Diagram -
DIAG-C80000-85016 C80000 REAR DIFFERENTIAL
View Diagram -
DIAG-E00500-85016 E00500 FRONT DIFFERENTIAL
View Diagram
