Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | THROTTLE PEDAL ASSY 332/P3548 | 1 | $92.70 | |||
| 2 | LEVER THROTTLE PEDAL 265/00630 | 1 | $60.83 | |||
| 3 | BRACKET CABLE 265/00629 | 1 | $194.64 | |||
| 4 | WASHER M_6 PLAIN 1420/0006Z 1420/0006D | 1 | $0.42 | |||
| 5 | SET-SCREW M_6 L-_20mm(KANBAN) 1315/0205Z | 1 | $0.65 | |||
| 6 | BOLT M8x60 1315/3314Z | 1 | $2.86 | |||
| 7 | SET-SCREW M_8 L-20mm 1315/0305Z | 1 | $1.25 | |||
| 8 | NUT M_8 STD SELF LOCK(KANBAN) 1370/0203Z | 1 | $0.26 | |||
| 9 | WASHER M_5 PLAIN(KANBAN) 1420/0005 1420/0005Z | 1 | $0.65 | |||
| 13 | Clip 03/305055 | 1 | $0.55 | |||
| 14 | SET SCREW M5x16 1315/0103Z | 1 | $1.92 | |||
| 16 | WASHER M10 PLAIN 1425/0008Z 1420/0008D | 1 | $0.23 | |||
| 17 | SET-SCREW M10 L-_50mm 1315/0412Z | 1 | $3.61 | |||
| 18 | SET-SCREW M10 L-_25mm 1315/0407 1315/0407Z | 1 | $5.34 | |||
| 19 | NUT M6 STD SELF LOCK(KANBAN) 1370/0103Z | 1 | $1.43 | |||
| 21 | GROMMET 2410/0215 | 1 | $44.16 | |||
Showing 1 to 16 of 16 parts
