Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 10 | FOOT PAD 589/10130 | 1 | $35.73 | |||
| 20 | NUT M10 STD SELF LOCK 1370/0303Z 1370/0303D | 1 | $0.65 | |||
| 30 | PIVOT PIN 478/00536 | 1 | $9.90 | |||
| 40 | WASHER M10 PLAIN 1425/0008Z 1420/0008D | 1 | $0.23 | |||
| 60 | (W) (P) EXTENSION SPRING (P564) 814/10210 | 1 | $14.65 | |||
| 70 | WASHER M_8 PLAIN 1420/0007Z 1420/0007D | 1 | $0.20 | |||
| 80 | NUT M_8 STD PLAIN 1370/0201Z 1370/0201D | 1 | $1.07 | |||
| 90 | SETSCREW M8x35 1315/0309D | 1 | $2.40 | |||
| 100 | WASHER M12 PLAIN 1420/0009D | 1 | $1.07 | |||
| 110 | SET-SCREW M12 L-_30mm 1315/0508D | 1 | $4.54 | |||
| 130 | LOCKNUT M5 1370/0003D | 1 | $3.05 | |||
| 140 | SET M5 X 30 HT (P564) 1315/0108Z | 1 | $0.41 | |||
| 150 | WASHER M_5 PLAIN 1420/0005D | 1 | $2.99 | |||
| 160 | '(W) (P) BEARING 16x20x20 (P564) OTP -S 831/00100 | 1 | $4.45 | |||
Showing 1 to 14 of 14 parts
Related Assemblies
-
DIAG-D2-1-4-400502 D2-1-4 THROTTLE CONTROL
View Diagram -
DIAG-D2-1-2-400502 D2-1-2 THROTTLE CONTROL
View Diagram -
DIAG-E1-1-1-400502 E1-1-1 DRIVE TRAIN HYDRAULICS
View Diagram
