| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| BOLT M8x60 1315/3314Z | 1 | $2.86 | ||||
| 2 | SET-SCREW M_6 L-_25mm 1315/0207Z 1315/0207D | 1 | $0.33 | |||
| 3 | WASHER M_6 PLAIN 1420/0006Z 1420/0006D | 1 | $0.42 | |||
| 4 | RIVET NUT (BR3) 826/01101 | 1 | $3.76 | |||
| 5 | CABLE 910/41400 | 1 | $295.91 | |||
| 6 | SWIVEL 262/20400 | 1 | $9.55 | |||
| 7 | NUT M6 THIN PLAIN (BR3) 1370/0102Z | 1 | $0.65 | |||
| 8 | BELLOWS 2000/0030 | 1 | $40.92 | |||
| 9 | U BOLT 256/71500 | 1 | $53.94 | |||
| 10 | NUT 2BA STD SELF LOCK 1358/0203Z | 1 | $7.92 | |||
| 11 | WASHER SPRING 1416/0003Z | 1 | $0.71 | |||
| 12 | BRACKET 263/08302 | 1 | $668.89 | |||
| 13 | CAP SCREW M6x10 1391/3201 | 1 | $3.41 | |||
| 14 | A113 50 mltrs PERMABOND 4101/0251 | 1 | $36.80 | |||
| 15 | NUT M6 STD SELF LOCK(KANBAN) 1370/0103Z | 1 | $1.43 | |||
| 16 | SPRING 814/00321 | 1 | $118.51 | |||
| 17 | LEVER THROTTLE PEDAL 265/00630 | 1 | $60.83 | |||
| 18 | SET-SCREW M_6 L-_20mm(KANBAN) 1315/0205Z | 1 | $0.65 | |||
| 20 | SET-SCREW M_8 L-20mm 1315/0305Z | 1 | $1.25 | |||
| 21 | NUT M_8 STD SELF LOCK(KANBAN) 1370/0203Z | 1 | $0.26 | |||
| 22 | BRACKET CABLE 265/00629 | 1 | $194.64 | |||
Showing 1 to 21 of 21 parts
Related Assemblies
-
DIAG-D1-7-1-404476 D1-7-1 VALVE, SERVO CONTROL COMPONENTS
View Diagram -
DIAG-D2-2-1-404476 D2-2-1 CONTROL PEDAL THROTTLE
View Diagram -
DIAG-D1-6-1-404476 D1-6-1 SERVO VALVE 3 SPOOL
View Diagram
