Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | PEDAL 124/69900 | 1 | $2,041.51 | |||
| 2 | BEARING 16x20x25 831/00064 | 1 | $23.64 | |||
| 3 | CIRCLIP EXTERNAL 2203/0022 | 1 | $1.22 | |||
| 4 | TORSION SPRING 814/00292 333/R2566 | 1 | $10.32 | |||
| 5 | ACCEL CABLE 910/37700 | 1 | $185.41 | |||
| 7 | PIN CLEVIS 2101/0002 | 1 | $34.68 | |||
| 8 | PIN SPLIT 1/16 2103/0305 | 1 | $0.44 | |||
| 9 | NUT 5/16UNF THIN PLAIN (P564) 1340/0102Z | 1 | $3.18 | |||
| 10 | (W) WASHER 5/16 MED PLAIN 1411/0002Z | 1 | $0.26 | |||
| 10 | WASHER M_8 PLAIN 1420/0007Z 1420/0007D | 1 | $0.20 | |||
| 11 | THIN HEX NUT 1/4 UNF 1340/0002Z | 1 | $6.38 | |||
| 12 | SPRING - OVERLOAD 814/00289 | 1 | $17.54 | |||
| 13 | PEDAL PAD ASSY. 122/40900 | 1 | $838.98 | |||
| 14 | NUT 1/2UNF THIN PLAIN 1340/0402Z | 1 | $0.81 | |||
| 15 | THROTTLE BRKT 123/00863 | 1 | $428.99 | |||
| 16 | SET SCREW M6x12 1315/0201Z | 1 | $0.62 | |||
| 17 | (W) (Pre-P) WASHER M6 SPRING (BR3) 1425/0006Z | 1 | $0.14 | |||
| 18 | WASHER M_6 PLAIN 1420/0006Z 1420/0006D | 1 | $0.42 | |||
| 19 | SPRING 02/200188 | 1 | $14.37 | |||
| 19A | SPRING 02/200517 | 1 | $11.22 | |||
| 20 | CONTROL BRACKET 02/200183 | 1 | $6.32 | |||
Showing 1 to 21 of 21 parts
Related Assemblies
-
DIAG-D2-1-2-399311 D2-1-2 CONTROL, THROTTLE
View Diagram -
DIAG-D2-2-1-399311 D2-2-1 CONTROL, DUMP
View Diagram -
DIAG-D1-2-1-399311 D1-2-1 VALVE LEVER LOCKING
View Diagram
