Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | SET-SCREW M_6 L-_20mm 1315/0205D | 1 | $0.57 | |||
| 2 | WA SENSOR BRKT 333/V2894 | 1 | $228.63 | |||
| 3 | PROXIMITY SWITCH 332/C8166 | 1 | $342.65 | |||
| 4 | WASHER M_6 PLAIN 1420/0006Z 1420/0006D | 1 | $0.42 | |||
| 5 | P CLIP (FOR 10 O.D. PIPE) 821/00410 | 1 | $16.76 | |||
| 6 | NUT M_6 STD SELF LOCK 1370/0103 1370/0103D | 1 | $0.17 | |||
| 7 | 437 HIGH LIFT SENSE BRKT 333/U8788 | 1 | $141.91 | |||
| 8 | PLAIN WASHER M4 (BR3) 1420/0004D | 1 | $0.58 | |||
| 9 | NUT M_4 STD SELF LOCK 1370/9403D | 1 | $1.43 | |||
| 10 | CAP SCREWS METRIC M4 X 25 1391/9407D | 1 | $3.09 | |||
| 11 | WASHER M_8 PLAIN 1420/0007Z 1420/0007D | 1 | $0.20 | |||
| 12 | SET-SCREW M_8 L-_25mm 1315/0307D | 1 | $0.37 | |||
| 13 | NUT M8 STD SELF LOCK 1370/0203D | 1 | $1.75 | |||
| 14 | NUT LOCK M10 (P545) 1371/0303D | 1 | $6.62 | |||
| 15 | BOLT M10X110 1315/3421D | 1 | $10.64 | |||
| 16 | WASHER M10 PLAIN 1425/0008Z 1420/0008D | 1 | $0.23 | |||
| 17 | BOLT PLATE 333/U9097 | 1 | $152.70 | |||
Showing 1 to 17 of 17 parts
Related Assemblies
-
DIAG-D190-35-1-404878 D190-35-1 OTHER MECHANICAL CONTROLS LIFT RESET
View Diagram -
DIAG-D190-15-1-404878 D190-15-1 OTHER MECHANICAL CONTROLS LIFT RESET, HT BUILDS, LUC
View Diagram -
DIAG-D190-10-1-404878-15799116 D190-10-1 OTHER MECHANICAL CONTROLS SUPER HIGH LIFT RESET, HT BUILDS, LUC
View Diagram
