Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 1 | LEVER ASSEMBLY 160/01935 | 1 | $602.06 | |||
| 3 | GA CONTROL ROD - TILT 160/13451 332/D7985 | 1 | $93.26 | |||
| 4 | CONTROL ROD ASSY. 332/D8034 | 1 | $113.70 | |||
| 5 | CLEVIS PIN 913/00023 529/38602 | 1 | $7.27 | |||
| 6 | SAFETY CLIP. 913/01102 | 1 | $3.18 | |||
| 7 | NUT M_8 STD SELF LOCK(KANBAN) 1370/0203Z | 1 | $0.26 | |||
| 8 | LABEL: PLACING PATTERN 817/18587 | 1 | $3.26 | |||
| 9 | LABEL: PLACING PATTERN 817/18588 | 1 | $3.26 | |||
Showing 1 to 8 of 8 parts
Related Assemblies
-
DIAG-D100-5-1-401708 D100-5-1 MECHANICAL CONTROL INSTALLATION ASSEMBLIES PLACE PATTERN LEVERS TILT LOCK
View Diagram -
DIAG-D110-5-1-401708 D110-5-1 LOADER CONTROLS COMMON PARTS
View Diagram -
DIAG-D110-10-1-401708 D110-10-1 LOADER CONTROLS CONTROL ROD ASSEMBLY 332/D7985
View Diagram
