Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| BRACKET, SHOVEL RESET 332/C8463 | 1 | $1,787.38 | ||||
| CABLE TIE - BLACK 200mm 826/01144 | 1 | $0.20 | ||||
| 1 | BAR Z LIFT RESET 265/01055 | 1 | $585.06 | |||
| 2 | RESET WEAR PAD 332/W3727 | 1 | $36.15 | |||
| 3 | PROXIMITY SWITCH - 2075 WIRE LG 701/80611 | 1 | $297.19 | |||
| 4 | CABLE TIE - BLACK 210mm 826/01453 | 1 | $1.49 | |||
| 5 | SPACER 830/00599 | 1 | $2.40 | |||
| 6 | HEX-SCREW M16 L-_30mm LG 1315/0708D | 1 | $5.07 | |||
| 7 | WASHER M16 PLAIN 1420/0011D | 1 | $1.43 | |||
| 8 | SET-SCREW M10 L-_30mm 1315/0408D | 1 | $1.55 | |||
| 9 | WASHER LARGE 1412/0007D | 1 | $5.07 | |||
| 10 | WASHER M10 PLAIN 1425/0008Z 1420/0008D | 1 | $0.23 | |||
| 11 | BAR RESET 331/15076 | 1 | $233.42 | |||
| 12 | (W) BOLT M8x80 1315/3318D | 1 | $3.67 | |||
| 13 | NUT M8 STD SELF LOCK 1370/0203D | 1 | $1.75 | |||
| 14 | WASHER M_8 PLAIN 1420/0007Z 1420/0007D | 1 | $0.20 | |||
Showing 1 to 16 of 16 parts
Related Assemblies
-
DIAG-D1-21-1-404913 D1-21-1 CONTROL, RESET LIFT ARM
View Diagram -
DIAG-D2-1-1-404913 D2-1-1 CONTROL, THROTTLE
View Diagram -
DIAG-E1-0-25-404913 E1-0-25 HYDRAULIC INSTALLATION ASSEMBLIES 2 SPOOL 446ZX STANDARD
View Diagram
