Kubota GR2010G C42000 UNIVERSAL JOINT/HST FAN Parts Diagram
Exploded-view parts diagram "C42000 UNIVERSAL JOINT/HST FAN" for the Kubota GR2010G. 15 parts are listed in this assembly. Click a numbered reference on the drawing, or use the search box, to see the genuine Kubota part number with price and stock, then add it to your cart. Supplied by Scholten's Equipment, authorized Kubota dealer with stores in Lynden and Burlington, Washington.
Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 010 | ASSY JOINT,UNIVERSAL K1261-13513 K1261-13514 | 1 | $760.92 | |||
| 020 | Bolt 01023-50630 | 1 | $1.57 | |||
| 030 | FAN, HST K1253-11140 | 1 | $7.65 | |||
| 040 | SPLINE BOSS, FAN K1253-11230 | 1 | $16.49 | |||
| 050 | BOLT, COATING K1254-11150 | 1 | $1.87 | |||
| 060 | M6 Flange Bolt 01754-50616 | 1 | $2.36 | |||
| 070 | SHAFT (FWD,DRIVE K1252-14542 | 1 | $133.98 | |||
| 070 | SHAFT, FWD DRIVE K1253-14540 K1253-14543 | 1 | $167.86 | |||
| 080 | BOSS, SPLINE K1253-14533 K1253-14534 | 1 | $63.00 | |||
| 090 | O-Ring Seal 04811-00150 04816-00150 | 1 | $2.01 | |||
| 100 | ASSY JOINT, UNIV K1253-01310 | 1 | $80.29 | |||
| 110 | YOKE (SLEEVE) K1261-01320 | 1 | $395.63 | |||
| 120 | YOKE(SHAFT) K1253-01330 K1253-01332 | 1 | $285.83 | |||
| 130 | YOKE (CLAMP) K1253-01350 | 1 | $183.70 | |||
| 140 | NIPPLE (GREASE) K1253-01360 | 1 | $22.32 | |||
Showing 1 to 15 of 15 parts
