Kubota RTV-X1120DG2 C41500 FRONT CASE Parts Diagram
Exploded-view parts diagram "C41500 FRONT CASE" for the Kubota RTV-X1120DG2, Kubota RTV-X1120DR2 and Kubota RTV-X1120DW2. 20 parts are listed in this assembly. Click a numbered reference on the drawing, or use the search box, to see the genuine Kubota part number with price and stock, then add it to your cart. Supplied by Scholten's Equipment, authorized Kubota dealer with stores in Lynden and Burlington, Washington.
Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| 005 | TRANSAXLE,ASSY K7421-10029 K7421-10035 | 1 | $9,007.65 | |||
| 010 | COVER,FRONT ** K7591-11112 K7591-11116 | 1 | $507.80 | |||
| 020 | COVER,FLYWHEEL K7731-11030 | 1 | $410.14 | |||
| 030 | Straight Pin 05012-00614 | 1 | $0.80 | |||
| 040 | BOLT, FLANGE 01130-51040 01133-51040 | 1 | $2.87 | |||
| 050 | BOLT,FLANGE 1J586-91020 01774-51004 | 1 | $9.06 | |||
| 060 | STUD 01519-51030 | 1 | $2.54 | |||
| 070 | NUT,M10x1.25 S/W K7591-11070 | 1 | $4.33 | |||
| 080 | O RING 04817-06470 | 1 | $8.66 | |||
| 090 | O-RING 04811-06670 | 1 | $7.26 | |||
| 100 | Flange Bolt 01754-50812 | 1 | $3.93 | |||
| 110 | Seal Washer 04717-00810 | 1 | $3.15 | |||
| 120 | CAP 52500-15462 | 1 | $10.64 | |||
| 160 | PIN, STRAIGHT 05012-00810 | 1 | $1.07 | |||
| 170 | PIN, STRAIGHT RE 05012-00816 | 1 | $1.31 | |||
| 180 | Bolt with Washer 01120-50825 01123-50825 | 1 | $1.21 | |||
| 190 | BOLT 01120-50840 01123-50840 | 1 | $1.77 | |||
| 200 | Spring Washer, Metric (M) 04512-50100 | 1 | $0.67 | |||
| 210 | Hex Nut, M10-1.25mm (6T) 70090-33403 02176-50100 | 1 | $0.80 | |||
| 220 | STUD 01517-51040 | 1 | $2.01 | |||
Showing 1 to 20 of 20 parts
