Scroll to zoom Click a part # to view details
| Ref # | Part Number | Qty. | Avl. | Price (USD) | Action | |
|---|---|---|---|---|---|---|
| ATC HVAC UNIT 400/A9970 | 1 | $2,437.09 | ||||
| 2 | Washer 30/925896 | 1 | $5.10 | |||
| 4 | Washer 30/925902 | 1 | $1.46 | |||
| 5 | SEAL ANTI CONDENSA 1mtr long 997/16700 | 1 | $103.75 | |||
| 8 | O RING 993/84100 | 1 | $15.60 | |||
| 9 | O RING 993/84300 993/99562 | 1 | $3.28 | |||
| 10 | Cable Tie 335/G7509 | 1 | $0.71 | |||
| 11 | Washer 332/D9708 | 1 | $3.17 | |||
| 13 | HOSE HEATER DRAIN (x2 1m lengths) 923/10101 | 1 | $17.67 | |||
| 14 | Washer shoulder 6. 30/925906 | 1 | $20.24 | |||
| 15 | Screw allen 30/925909 | 1 | $39.59 | |||
| 16 | BOLT ALLEN 30/925910 | 1 | $46.97 | |||
| 17 | PLATE CLAMP TXV 30/925911 | 1 | $32.36 | |||
| 18 | Seal 333/P8394 | 1 | $7.61 | |||
| 19 | NUT 331/36622 | 1 | $9.15 | |||
| 20 | PLATE CLAMP 30/925913 | 1 | $8.23 | |||
| 21 | Spacer nylon 332/D9715 | 1 | $11.39 | |||
| 22 | Cap 923/10138 | 1 | $12.71 | |||
| 23 | VALVE 30/926003 923/10098 | 1 | $266.41 | |||
| 24 | Screw No 8 x 3/8 333/G8065 | 1 | $0.62 | |||
| 25 | Grommet 332/H7298 | 1 | $2.93 | |||
| 26 | Clip sensor 332/H7299 | 1 | $14.49 | |||
| 27 | ADAPTOR 30/926653 | 1 | $18.90 | |||
| 28 | Screw 332/H7300 | 1 | $8.41 | |||
| 29 | Screw 335/E1041 | 1 | $1.13 | |||
| 30 | Capscrew 334/P1288 | 1 | $2.47 | |||
| 32 | THERMISTOR 400/01980 332/R0181 | 1 | $89.36 | |||
| 34 | Hose - Water Feed 335/E9707 | 1 | $7.04 | |||
| 35 | SENSOR 332/F2308 400/Y8617 | 1 | $67.57 | |||
| 36 | Check Valve 335/E4681 | 1 | $15.33 | |||
| 38 | Blower 335/E9706 | 1 | $488.48 | |||
| 39 | Gasket Coil Support 335/E9690 | 1 | $5.16 | |||
| 40 | Heater Coil 335/E9709 | 1 | $305.64 | |||
| 41 | Gasket Coil Top 335/E9695 | 1 | $91.57 | |||
| 42 | Gasket Outlet 335/E9696 | 1 | $18.46 | |||
| 43 | Fresh Air Gasket 335/E9697 | 1 | $56.99 | |||
| 45 | Seal Air Off 335/E9698 | 1 | $16.72 | |||
| 46 | Actuator 335/E9732 | 1 | $91.44 | |||
| 47 | Insulation Case Front 335/E9702 | 1 | $15.87 | |||
| 48 | Module 336/A1313 400/08171 | 1 | $167.81 | |||
| 49 | Top Cover Insulation 335/E9703 | 1 | $101.67 | |||
| 51 | Water valve 400/01129 | 1 | $164.15 | |||
| 54 | Gasket Top Cover 335/E9720 | 1 | $60.17 | |||
| 56 | Evaporator coil 400/L6970 | 1 | $680.29 | |||
| 66 | ASSY, TEMPERATURE SENSOR 30/927133 332/R0375 | 1 | $174.15 | |||
Showing 1 to 45 of 45 parts
Related Assemblies
-
DIAG-C340-55-1-393731 C340-55-1 HEATER/AIR CON ASSEMBLY CAB HVAC COMPONENTS
View Diagram -
DIAG-C340-130-1-393731 C340-130-1 HEATER/AIR CON ASSEMBLY DETAILS AIR INTAKE FILTER
View Diagram -
DIAG-C340-45-1-393731 C340-45-1 HEATER/AIR CON ASSEMBLY MODE DOOR ASSEMBLY
View Diagram
