C330-10-1 SWITCHES PROXIMITY Parts Diagram | JCB

Scroll to zoom Click a part # to view details

Ref #	Part Number	Qty.	Avl.	Price (USD)	Action
	PROXIMITY SWITCH 701/80243 701/80345	1	AVAILABLE TO ORDER	$246.86	Quantity
2	Multi-way housing 7213/0014	1	AVAILABLE TO ORDER	$2.68	Quantity
4	Terminal Pin 7204/0028 7204/0025	1	AVAILABLE TO ORDER	$4.17	Quantity

Showing 1 to 3 of 3 parts
